Hifonics ZS653 ZEUS 6.5 Inch Speakers
Hifonics ZS653 ZEUS 6.5 Inch Speakers is backordered and will ship as soon as it is back in stock.
Care information
Care information
Display general product information or specific product information using metafields.
Delivery and Shipping
Delivery and Shipping
Add some general information about your delivery and shipping policies.
Hifonics ZS653 ZEUS 6.5 Inch Speakers
Hifonics ZS653 ZEUS 6.5 Inch Speakers is backordered and will ship as soon as it is back in stock.
Highlight title
Text to highlight a key feature of your product
Description
Description
The Hifonics ZS653 ZEUS is a 6.5-inch 3-way car audio coaxial speaker system designed to deliver full-range sound with clear dynamic response. Engineered with Alpha-Cellulose poly woofer cones and moisture-resistant rubber surrounds, it produces punchy mid-bass and deep low frequencies while resisting environmental wear.
High frequencies are handled by a 1-inch Neo-Mylar soft dome tweeter paired with a Kapton voice coil former for efficient heat dissipation and clear, distortion-free output. The speakers feature an anti-resonant stamped steel basket and an overcoil cooling design that channels air across the pure copper voice coil through an epoxy-infused natural fiber spider.
Equipped with an integrated passive Butterworth crossover network, the system ensures seamless frequency transitions between the mid-bass and high-frequency elements. Designed for universal fitment in OEM dash and door speaker locations, these 4-ohm speakers handle up to 50 watts RMS and 300 watts peak power.
Key Features
| Brand | Hifonics |
| Series | ZEUS |
| Model | ZS653 |
| Type | 3-Way Coaxial Speaker |
| Speaker Size | 6.5" |
| RMS Power Handling | 50 W |
| Peak Power Handling | 300 W |
| Impedance | 4 Ohms |
| Frequency Response | 40Hz-22kHz |
| Sensitivity | 88 dB |
| Crossover Slope | 4kHz 12dB |
| Mounting Diameter / Cut Out | 14.2 cm |
| Outside Diameter | 17.8 cm |
| Mounting Depth | 5.4 cm |
| Dimensions | 37.8 × 21.4 × 10.2 cm |
| Weight | 1.6 kg |
| Color | Black |
| CEA Standards | CEA426B |
Highlights
| Component | Description |
|---|---|
| Tweeters | 1 inch: Clear highs while handling plenty of power without sound harsh. Neo-Mylar Soft Dome Tweeter: Impact Resistant Tweeter Elements, Great sound quality and increased reliability. Kapton: Lightweight and efficiently dissipates heat. |
| Cone Material | Alpha-Cellulose Cones: Light weight for speed and very rigid for deep bass. |
| Surround / Cone Coupling | Rubber: Moisture Resistant Rubber Surround with high Mid-Bass Impact. High Temperature Adhesive: Special adhesive is chosen to create a permanent bond between the cone and the surround. |
| Voice Coil / Former Assembly | Pure Copper: Creates strong magnetic field with a very thin extrusion. Kapton: Lightweight and efficiently dissipates heat. |
| Spider | Epoxy infused Natural Fiber: Natural fiber allows flexibility while the epoxy which gives strength during the manufacturing process. |
| Cooling System | Overcoil: Air is exchanged over the voice coil through the spider. |
| Crossover | Passive Butterworth: Smooth transition of frequencies from midrange/midbass to the tweeter element. |
| Frame | Anti-Resonant Stamped Steel Basket: Very strong with minimal harmonics or distortions from flex or ringing. |
| Motor | Ferrite Magnet: Creates a strong magnetic field while remaining small enough to fit nearly every application. |
| Connectors | Spade: Use spade connectors or solder direct for the best connection. |
| Grills | No: Typically used in factory dash replacement locations where grills are not required. |
Compatibility
Universal fitment for vehicles configured for 6.5-inch speakers with a 14.2 cm (5.59 in) cut-out diameter and 5.4 cm (2.13 in) mounting depth.
Warranty
| Document | Description |
|---|---|
| View/Download (706.8 KB) | Hifonics ZEUS Speakers (ZS) Quick Start Guide (Rev1) |
What's included
- Pair of Hifonics ZS653 6.5" 3-Way Coaxial Speakers
- Quick Start Guide
Downloads
