Diamond Audio | SKU:
MICRO84DSP
Diamond Audio 4 Channel Full Range Digital Amplifier with 2CH DSP Output
Regular price
$1,000,000.00
Unit price
Shipping calculated at checkout.
Key features
- Amplifier channels: 4
- RMS per channel at 4 ohms: 90 W
- RMS per channel at 2 ohms: 165 W
- Frequency response: 10 Hz–25 kHz
- Signal-to-noise ratio: Greater than 96 dB
- Digital signal processor: 6 inputs and 6 outputs
Diamond Audio 4 Channel Full Range Digital Amplifier with 2CH DSP Output is backordered and will ship as soon as it is back in stock.
Diamond Audio | SKU:
MICRO84DSP
Regular price
$1,000,000.00
Unit price
Shipping calculated at checkout.
Diamond Audio 4 Channel Full Range Digital Amplifier with 2CH DSP Output is backordered and will ship as soon as it is back in stock.
Description
Description
Diamond Audio MICRO84DSP: 4 Channel Full Range Digital Amplifier with 2CH DSP Output.
Features and specifications
- 165W x 4CH @ 2Ω / 90W x 4CH @ 4Ω / 330W x 2CH @ 4Ω Bridged RMS Power Output
- Signal to Noise Ratio: > 96dB
- Frequency Response: 10-25KHz
- Channel Separation: > -68dB
- Integrated 6-In / 6-Out Digital Signal Processor Build in
- Additional 2 Channel (2-In / 2-Out) DSP Signal Output
- 15 Band Parametric EQ
- Fully Adjustable Crossovers
- Tuning Operating Software: Windows / Android / IOS
- Advanced CSR 5.0 Bluetooth Module for Music Streaming and AppControl on Mobile Phone
- External Antenna for Enhanced Bluetooth Signal Reception
- Dimensions: 8.3" x 4.1" x 1.46" / 210.5 x 103 x 37.2 mm
- DSP Remote Controller Ready (Optional DADSP9RC)
