The Diamond Audio MICRO84U is a compact four-channel Class D amplifier for car, motorcycle, marine and powersports audio systems. Its conformal-coated circuit board supports all-weather installations, and selectable input and turn-on modes accommodate different system layouts.
Power and specifications
- RMS output: 80 watts × 4 at 4 ohms; 150 watts × 4 at 2 ohms; 300 watts × 2 bridged at 4 ohms.
- Input sensitivity: 0.2–10 volts.
- Crossover: 40–400 Hz, with a 12 dB/octave slope.
- Frequency response: 10 Hz–33 kHz.
- Selectable REM, VOX and DC turn-on modes.
- Selectable two-channel or four-channel input mode.
- Dimensions: 9.1 × 4.1 × 1.46 inches (230.5 × 103 × 37.2 mm).
- RCA input and speaker-output harness kits included.
