American Bass HD Series 12" Subwoofer

The American Bass HD Series 12" Subwoofer is a heavy-duty 12-inch driver engineered for hardcore car audio installations, delivering gut-wrenching bass and reliable high-power handling for serious enthusiasts.

• RMS Power: 2000W continuous power handling, meaning it can sustain high-output playback without bottoming out when driven by an appropriate amplifier.
• Max Power: 4000W peak, providing headroom for brief dynamic bursts and transients without clipping when the amp supply spikes.
• Impedance (OHMS): D1 / D2, offering dual-impedance options for flexible wiring and amplifier matching.
• Sensitivity: 86.5 dB, indicating how effectively the woofer converts input power into SPL; actual output depends on enclosure and power used.
• Mounting Depth: 8.38 in, a practical depth consideration for fitment behind factory panels or in shallow mounting locations.
• Cutout Size: 11.4 in, the required hole diameter for installation in an enclosure or mounting surface.
• Ported Box (FT3): 2.25 – 2.75 ft³, the recommended enclosure volume range to optimize bass output and port tuning in a ported design.
• Magnet Size: 350 oz, providing substantial motor strength for controlled cone motion under high power.
• Voice Coil Size: 3 in, a large diameter coil for improved heat dissipation and power handling during extended high‑level playback.
• Basket Type: Cast, offering rigid support for high excursion and durability in demanding install environments.
• Recommended Amp (Pair): VFL 4K, the suggested amplifier pairing for a two‑subwoofer configuration to achieve balanced, high‑output performance.

In a real car audio build, this subwoofer excels in a ported enclosure around 2.25–2.75 ft³ and benefits from the strong 350 oz magnet and 3" voice coil for sustained bass control at high power. The cast basket and dual-impedance wiring options enable a robust, flexible setup when paired with a high‑performance amp like the VFL 4K across a pair, delivering loud, low-distortion bass suitable for enthusiasts chasing deep, accurate low-end impact.
