Deaf Bonce Apocalypse ATOM 1600 PRO 1600 Watt Power Amplifier

The Deaf Bonce Apocalypse ATOM 1600 PRO is a mono, Class D power amplifier built for bass-forward car audio systems, delivering up to 1600 W RMS at 1 ohm from a 14.4 V supply for demanding subwoofer applications. Its compact 9 x 5.5 x 2.1 inch footprint makes high-current bass Headroom feasible in tight trunks or under seats.

• Class: D-class amplifier; designed for efficient, high-current operation in a compact chassis, ideal for bass-focused installations.
• Number of the channels: 1; provides a single, dedicated mono channel optimized for a subwoofer or bass driver.
• Frequency response: 10 - 250 Hz; ensures the amp primarily handles low-frequency content, shaping bass response for woofer performance.
• 1 Ohm RMS Power (14.4 V): 1600 W; demonstrates the high power potential when the vehicle electrical system is around 14.4 V, supporting strong bass output at low impedance.
• 1 Ohm RMS Power (12 V): 1430 W; shows substantial power delivery even at a lower supply voltage typical of some vehicle conditions.
• 2 Ohm RMS Power (14.4 V): 1010 W; indicates how impedance changes affect available power at a standard car voltage.
• 4 Ohm RMS Power (14.4 V): 550 W; provides a view of the power curve as the load impedance increases.
• Minimum permissible load on the channel: 1 Ohm; you can run as low as 1 ohm to maximize current delivery, but not lower according to the spec.
• Low pass filter: 40 - 250 Hz; lets you set the upper cutoff to tailor the amp to your enclosure and subwoofer parameters.
• Crossover: 12 dB/Oct; defines the attenuation slope, affecting how quickly frequencies roll off beyond the set point.
• Subsonic filter: 10 - 50 Hz; helps suppress inaudible ultra-low frequencies that can waste power and strain the amp and speaker.
• Bass frequency adjustment: 35 - 90 Hz; offers targeted tuning of bass emphasis to match enclosure and listening preference.
• Input terminal: 4 Ga; a heavy-gauge input capable of carrying high-current signals from the head unit or processor.
• Output terminal: 10 Ga; large-gauge speaker output designed for low-resistance connection to a subwoofer voice coil.
• Working voltage: 9 - 15 V; aligns with typical automotive electrical ranges, ensuring operation across different vehicle electrical conditions.
• Signal-to-noise ratio: ~93 dB; indicates a quiet signal floor relative to noise, contributing to cleaner bass output.
• Size (WxLxH): 9 x 5.5 x 2.1 inch; compact form factor suitable for installation in limited spaces behind seats or in trunks.

The ATOM 1600 PRO is well-suited as the dedicated subwoofer amplifier in a high-power system, delivering substantial current to a single bass driver and offering flexible tuning options (LPF, subsonic, and bass adjust) to tailor bass response to your vehicle and enclosure. Its heavy-gauge connections and low-noise performance support clean, high-output bass without excessive heat or electrical strain in typical car installations.
