Audio Ace Str8 NST Series 8" Subwoofer Dual 2 Ohm

The Audio Ace Str8 NST Series 8" Dual 2 Ohm subwoofer delivers up to 1000W RMS in an 8-inch package, engineered for big output on a budget.

• Impedance: Dual 2 Ohm
• Power handling: 1000W RMS
• Voice coil: 2.5 inch epoxy coated voice coil
• Mounting depth: 6.5 inches
• Cutout: 7.264
• Motor: 159 oz motor
• QES:.616
• QMS: 5.529
• QTS:.554
• Fs: 54 Hz
• Sd: 196.07
• SPL: 82
• BL: 19.132
• XMAX: 15.5 each way
• Box recommendations:.7-1.1 cubic foot
• Port area per cubic foot: 10-13 square inches of port area per cubic foot
• Box tuning: 32-38 Hz
• Enclosure note: Not recommended for sealed applications

In a vented enclosure sized within.7–1.1 cubic feet per sub and tuned to 32–38 Hz, this NST8 yields strong, extendable bass with controlled cone motion. The 159 oz motor and 15.5 each-way XMAX support substantial excursion, helping bass reach deeper than typical 8" budget subs when paired with an appropriate amplifier. The epoxy-coated 2.5" voice coil enhances durability during high-signal operation, while the dual 2-ohm configuration offers wiring flexibility to fit common car audio layouts. For best results, use a ported enclosure within the recommended volume and note that sealed enclosures are not advised for this model.
