Sundown Audio Nightshade NS-Series NS6 10" 3500W Subwoofer NS v.6
Key features
- Subwoofer size: 10.0 inches
- RMS power per subwoofer: 3500 W
- Voice-coil options: D1, D2
- Mounting depth: 12.24"
- Cutout diameter: 10.1"
- Driver displacement: .23 cu ft
Sundown Audio Nightshade NS-Series NS6 10" 3500W Subwoofer NS v.6 - D2 is backordered and will ship as soon as it is back in stock.
Sundown Audio Nightshade NS-Series NS6 10" 3500W Subwoofer NS v.6 - D2 is backordered and will ship as soon as it is back in stock.
Description
Description
Sundown Audio Nightshade NS-Series NS6 10" 3500W Subwoofer NS v.6
The Nightshade NS-Series NS6 10" 3500W Subwoofer NS v.6 is a 10-inch car subwoofer driver for a separately designed bass enclosure. Sundown specifies 3,500 watts RMS power handling for this model. Choose the listed voice-coil option to suit the amplifier and final wired load.
D1 denotes dual 1-ohm voice coils; D2 denotes dual 2-ohm voice coils.
Manufacturer specifications
- Xmax: 35mm
- RMS Power: 3500 W
- Peak Power: 7000 W
- Displacement: .23 cu ft
- Mounting Depth: 12.24"
- Outside Diameter: 11.81"
- Cutout Diameter: 10.1"
- Sealed Enclosure: Not Recommended
- Ported Enclosure: 1.5 cu ft
- Recommended Port Tuning: D1 Model: 32 hz; D2 Model: 32hz
- Recommended Port Area: 22 sq in
Enclosure and installation planning
This listing is for the subwoofer driver. Use the manufacturer’s dimensions and enclosure recommendations when planning the installation; no vehicle-specific fitment is asserted. Confirm the mounting cutout, available depth, enclosure volume, and amplifier load before assembly.
Recommended Monoblock Amplifiers
Power-matched options for one subwoofer or one complete loaded enclosure. We aim to include same-brand choices when their ratings qualify.
Loading amplifier suggestions…
Suggestions use 75–125% of the subwoofer’s RMS rating at the wiring load shown. Check wiring, enclosure needs, electrical capacity and installation space. Set gain and filters correctly to avoid overpowering the subwoofer. Buying more than one subwoofer changes the match.
