Audiopipe APHT-2000.4-H2 Full Range Class D Transistor Amplifier
Key features
- Amplifier channels: 4
- RMS per channel at 4 ohms: 200 W
- RMS per channel at 2 ohms: 300 W
- Class D transistor design: PWM technology and efficient circuitry help deliver power while reducing heat generation.
- Flexible output: Choose among the listed four-channel ratings or bridged output to suit your system design.
- High- and low-pass filters: Built-in 90 Hz filters help shape the frequency range sent through your system.
Audiopipe APHT-2000.4-H2 Full Range Class D Transistor Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Power a full-range car audio setup with the Audiopipe APHT-2000.4-H2 four-channel Class D transistor amplifier. Its output options support four-channel or bridged configurations, while Class D circuitry is designed for efficient operation with reduced heat generation.
Key Features & Benefits
- Class D transistor design: PWM technology and efficient circuitry help deliver power while reducing heat generation.
- Flexible output: Choose among the listed four-channel ratings or bridged output to suit your system design.
- High- and low-pass filters: Built-in 90 Hz filters help shape the frequency range sent through your system.
- Wide frequency response: The 20 Hz–20 kHz response supports full-range audio reproduction.
- Broad input sensitivity: The 0.2 V–12 V range accommodates varied input signal levels.
Technical Specifications
| Specification | Value |
|---|---|
| Maximum power | 3000 Watts |
| Continuous power output @ 1% THD, 1kHz — Mono @ 4 Ohms | 4 x 200 Watts |
| Continuous power output @ 1% THD, 1kHz — Mono @ 2 Ohms | 4 x 300 Watts |
| Continuous power output @ 1% THD, 1kHz — Bridged @ 4 Ohms | 2 x 600 Watts |
| Frequency response (-1dB) | 20Hz–20kHz |
| Signal-to-noise ratio | ≥85dB |
| Input sensitivity | 0.2V–12V |
| Under-voltage protection | 9V |
| High-pass filter | 90Hz |
| Low-pass filter | 90Hz |
| Bass boost | N/A |
Why Choose This Product?
The APHT-2000.4-H2 gives you multiple rated output options in one full-range amplifier. Use its four-channel output for a speaker system, or consider the listed bridged rating when planning a different system layout. Its crossover filters provide control over frequency routing, while the wide response range is suited to full-range audio applications.
Installation & Compatibility Notes
Plan your system around the amplifier’s listed load ratings and output configuration. Confirm that your speakers and installation match the intended load before connecting the amplifier. Follow the product’s installation instructions for wiring and setup.
Frequently Asked Questions
Can the APHT-2000.4-H2 run in a bridged configuration?
Yes. Its listed bridged rating is 2 x 600 Watts at 4 Ohms.
What are the four-channel power ratings?
The listed ratings are 4 x 200 Watts at 4 Ohms and 4 x 300 Watts at 2 Ohms, at 1% THD and 1kHz.
What crossover filters does this amplifier have?
It has built-in high-pass and low-pass filters, each listed at 90Hz.
What input sensitivity range does it support?
The input sensitivity is 0.2V–12V.
