Audiopipe TXX-BDD2-12 12” Double Stack High Power Subwoofer
Key features
- Subwoofer size: 12.0 inches
- RMS power per subwoofer: 800 W
- Voice-coil options: D4
- FREQUENCY RESPONSE: 22-900Hz
- SENSITIVITY: 88dB
- MOUNTING DEPTH: 7.375” (187mm)
Audiopipe TXX-BDD2-12 12” Double Stack High Power Subwoofer is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The Audiopipe TXX-BDD2-12 12-inch double stack subwoofer brings high-power bass to a car audio system. Its 800-watt RMS rating, dual voice coil, and composite cone are built for powerful low-frequency playback.
A die-cast aluminum basket, foam surround, and quad-stitched surround support the subwoofer’s construction. Multi-connect terminals let you wire the subwoofer in parallel or series.
Key Features & Benefits
- Power handling: The subwoofer is rated at 800 watts RMS and 1600 watts peak.
- Composite cone: Paper and fiberglass construction combines the stated materials in the cone.
- Dual voice coil: The 2.5-inch, 4-layer black aluminum BASV coil supports high-power output.
- Foam surround: The air cushion foam surround and high excursion support bass output.
- Reinforced construction: Quad stitching reinforces the cone and surround, while the die-cast aluminum basket is designed to reduce unwanted resonance.
- Flexible connections: Multi-connect terminals support parallel or series wiring.
Technical Specifications
| Specification | Value |
|---|---|
| Product type | 12” Double Stack High Power Subwoofer |
| Peak power | 1600 watts |
| RMS power | 800 watts |
| P.M.P.O. power | 1600 watts |
| Frequency response | 22-900Hz |
| Sensitivity | 88dB |
| Magnets | 2 magnets (150 Oz) |
| Cone | Paper + fiberglass composite |
| Surround | Air cushion foam; quad-stitched with blue stitching |
| Voice coil | 2.5" 4-layer black aluminum (BASV) dual voice coil |
| Dust cap | Large inverted composite fiberglass |
| Motor structure | Deep bumped T-yoke with oversized pipe shape |
| Basket | Powdered black paint die-cast aluminum |
| Terminals | Multi-connect; parallel or series configurations |
| Impedance | 2×4 Ohms |
| Mounting depth | 7.375” (187mm) |
| Sealed enclosure | 1.5 cu Ft. |
| Vented enclosure | 2.5 cu ft. |
| Port | 2.5“ × 12“ × 14" |
Why Choose This Product?
The TXX-BDD2-12 pairs a high RMS power rating with a dual voice coil and multiple connection options. Its composite fiberglass dust cap is described as supporting cooling and structural durability, while the die-cast basket is designed to limit unwanted resonance.
The listed sealed and vented enclosure volumes give you specific figures to consider when planning a subwoofer enclosure. Its mounting depth is also useful when checking available installation space.
Installation & Compatibility Notes
Check that your enclosure provides the listed mounting depth and is designed for the specified sealed or vented volume. The listed port dimensions apply to the vented enclosure information.
Confirm that your amplifier and wiring plan are appropriate for the 2×4-ohm impedance. The terminals support parallel or series configurations; choose a wiring arrangement that matches your system requirements.
Frequently Asked Questions
What are the power ratings for the Audiopipe TXX-BDD2-12?
It is listed at 800 watts RMS, 1600 watts peak, and 1600 watts P.M.P.O.
What impedance does this subwoofer have?
The listed impedance is 2×4 Ohms. Check your amplifier’s supported load before choosing a wiring configuration.
How much mounting space does it need?
The mounting depth is 7.375” (187mm). Allow for the rest of the subwoofer and enclosure when planning installation space.
What enclosure sizes are listed?
The listed volumes are 1.5 cu Ft. for a sealed enclosure and 2.5 cu ft. for a vented enclosure. The listed port dimensions are 2.5“ × 12“ × 14".
