Hifonics ZS65CXS ZEUS 6.5 Inch Shallow Speakers

Name: Hifonics ZS65CXS ZEUS 6.5 Inch Shallow Speakers
Brand: Hifonics
SKU: 806576226758
Price: 34.99 USD
Availability: InStock

$34.99 $41.99

Shipping calculated at checkout.

Key features

Speaker size: 6.5″
RMS power per speaker: 50 W
Speaker impedance: 4.0 ohms
Frequency response: 60Hz-20kHz
Cone: Alpha-cellulose
Voice coil: Copper winding on Kapton former

Description

The Hifonics ZS65CXS ZEUS Series delivers high-performance audio in a shallow-mount coaxial configuration engineered for tight vehicle installations. Built with rigid Alpha-Cellulose poly woofer cones and moisture-resistant rubber surrounds, these speakers produce responsive mid-bass impact without distortion.

High frequencies are handled by 1-inch Neo-Mylar soft dome tweeters, offering clear, impact-resistant sound reproduction paired with heat-dissipating Kapton voice coil formers. An overcoil cooling system circulates air through the epoxy-infused natural fiber spider to ensure reliable operation under continuous load.

Housed in anti-resonant stamped steel baskets with compact ferrite magnets, this 3-way system fits factory speaker locations with minimal mounting depth. Protective grilles and standard spade connector terminals provide versatile installation options for universal car audio upgrades.

Key Features

Brand	Hifonics
Series	ZEUS
Model	ZS65CXS
Product Type	3-Way Shallow Mount Coaxial Speaker Pair
Speaker Size	6.5"
RMS Power Handling	50 W
Peak Power Handling	300 W
Impedance	4 Ohms
Sensitivity	88 dB
Frequency Response	60 Hz - 20 kHz
Crossover Slope	4 kHz 12 dB
Mounting Depth	4.2 cm
Mounting Diameter / Cutout	14.2 cm
Overall Diameter	17.8 cm
Dimensions	37.8 × 21.4 × 10.2 cm
Weight	1.5 kg
Color	Black
Cone Material	Alpha-Cellulose
Surround Material	Rubber
Tweeter Type	1" Neo-Mylar Soft Dome
Basket Material	Stamped Steel
Magnet Type	Ferrite
Connector Type	Spade / Solder

Highlights

Feature	Description
Tweeters	1 inch: Clear highs while handling plenty of power without sounding harsh. Neo-Mylar Soft Dome Tweeter: Impact Resistant Tweeter Elements, Great sound quality and increased reliability. Kapton: Lightweight and efficiently dissipates heat.
Cone Material	Alpha-Cellulose Cones: Light weight for speed and very rigid for deep bass.
Surround / Cone Coupling	Rubber: Moisture Resistant Rubber Surround with high Mid-Bass Impact. High Temperature Adhesive: Special adhesive is chosen to create a permanent bond between the cone and the surround.
Voice Coil / Former Assembly	Pure Copper: Creates strong magnetic field with a very thin extrusion. Kapton: Lightweight and efficiently dissipates heat.
Spider	Epoxy infused Natural Fiber: Natural fiber allows flexibility while the epoxy gives strength during the manufacturing process.
Cooling System	Overcoil: Air is exchanged over the voice coil through the spider.
Crossover	Passive Butterworth: Smooth transition of frequencies from midrange/midbass to the tweeter element.
Frame	Anti-Resonant Stamped Steel Basket: Very strong with minimal harmonics or distortions from flex or ringing.
Motor	Ferrite Magnet: Creates a strong magnetic field while remaining small enough to fit nearly every application.
Connectors	Spade: Use spade connectors or solder direct for the best connection.
Grills	Yes: Protects the speaker from accidental damage. Not used if speaker is mounted behind vehicle panel.

Compatibility

Universal fit for standard 6.5" vehicle speaker locations requiring a shallow mounting depth of 4.2 cm (1.65 in) and a cutout diameter of 14.2 cm (5.59 in).
