DS18 G700.2 GEN-X Full-Range Class D 2-Channel Amplifier 700 Watts
DS18 G700.2 GEN-X Full-Range Class D 2-Channel Amplifier 700 Watts is backordered and will ship as soon as it is back in stock.
Highlight title
Text to highlight a key feature of your product
Description
Description
DS18 G700.2 GEN-X Full-Range Class D 2-Channel Amplifier is a compact, high-efficiency power stage designed for demanding two-channel car audio installs, delivering up to 360W bridged at 4 ohms and 2x180W at 2 ohms from a 700W peak rating.
- Amplifier Class: Digital (D) design for high efficiency and smaller footprint in tight mounting locations.
- Amplifier Type: Full Range
- Number of Channels: 2CH
- Minimum Impedance: 2 ohms, enabling stable operation with tougher speaker loads.
- RMS Power @ 4 Ω: 2 x 100W
- RMS Power @ 2 Ω: 2 x 180W
- RMS Power (Bridged @ 4 Ω): 1 x 360W
- Total Watts (Peak): 700W
- Frequency Response: 20Hz–20kHz
- Signal-to-Noise Ratio: >90dB
- Efficiency @ 4 Ω: 0.94
- Damping Factor: 78
- Input Impedance: 22K
- Crossovers: Selectable LPF/FLAT/HPF
- X-Over Range: 50Hz–2kHz
- Bass Boost: 0–12dB
- Bass Boost Frequency: 45Hz
- Infrasonic Filter: No
- Phase Selector: No
- Low-Level Input: 0.25–6V
- High-Level Input Compatibility: Direct signaling to factory radios
- Surface Mount Technology: Yes, enables flexible placement and build options
- LED Indicators: Power / Protection / Clip
- Power Input Terminal Size: 4ga
- Fuse Size: 2 x 20A
- Remote Level Control: No
- Cooling: No cooling fan
- Body Color / Finish: Matte black
- Dimensions: Length 8.1" (205mm); Width 4.72" (120mm); Height 1.96" (50mm); Heatsink Length 6.2" (158mm)
The G700.2 GEN-X pairs precise 2-channel power delivery with flexible crossover control, allowing you to shape the front stage or bridge for mono use while maintaining reliable protection and clear signal integrity. Its high-level input compatibility simplifies integration with factory radios, and the compact, fanless design helps preserve space in tighter installs without sacrificing performance.
