American Bass Godfather COMP 15D 20,000 Watt Monoblock Amplifier

Product Overview

Build a dedicated subwoofer stage around the American Bass Godfather COMP 15D monoblock amplifier. Its single-channel digital design delivers up to 20,000W RMS at 1Ω, with adjustable filters, bass boost, and phase control for shaping your system’s low end.

Use it in a high-power bass build where the subwoofer load and supporting electrical system are designed for the amplifier’s ratings.

Key Features & Benefits

• Single-channel digital design: A focused monoblock layout is made for powering a subwoofer stage.
• Multiple RMS ratings: Choose between 20,000W at 1Ω, 13,000W at 2Ω, or 7,600W at 4Ω according to your system design.
• Adjustable bass filters: Set the subsonic and low-pass filters within their stated ranges to shape the signal sent to your subwoofers.
• 45Hz bass boost: Adjust boost from 0–9dB for a targeted change around 45Hz.
• Phase adjustment: The 0–180-degree range gives you an adjustment for integrating the amplifier’s output with other drivers.
• Over 90% efficiency at 4Ω: The stated efficiency helps reduce heat generation during sustained bass playback.

Technical Specifications

Why Choose This Product?

The Godfather COMP 15D combines high RMS output options with controls for tuning the bass signal. Its 95dB signal-to-noise ratio and 0.1% THD at 4Ω are listed alongside the power ratings, while a damping factor of 500 is specified for subwoofer control.

The 10Hz–50Hz subsonic filter and 35Hz–250Hz low-pass filter let you adjust the signal range. Bass boost and phase controls add further tuning options for a dedicated subwoofer stage.

Installation & Compatibility Notes

Match the amplifier’s 1Ω, 2Ω, or 4Ω RMS rating to the final subwoofer load. Confirm that the subwoofers and the rest of the system are suited to the selected load and power level before installation.

The listed fuse rating is 1800A. Have a qualified installer assess the electrical system and installation requirements for this high-current amplifier. The input sensitivity range is 6V–0.2V.

Frequently Asked Questions

How much RMS power does the Godfather COMP 15D produce?

It is rated at 20,000W RMS at 1Ω, 13,000W RMS at 2Ω, and 7,600W RMS at 4Ω.

What do the subsonic and low-pass filters adjust?

The subsonic filter adjusts from 10Hz–50Hz, and the low-pass filter adjusts from 35Hz–250Hz.

Can I adjust bass boost and phase?

Yes. Bass boost is adjustable from 0–9dB at 45Hz, and phase adjustment ranges from 0–180 degrees.

What should I check before choosing a subwoofer load?

Confirm the final load and power requirements of your subwoofer system match one of the amplifier’s listed RMS ratings.

What fuse rating is listed?

The amplifier’s fuse rating is 1800A. The strapped fuse rating is listed as N/A.
