American Bass Godfather Series 15" Subwoofer
Key features
- Subwoofer size: 15.0 inches
- RMS power per subwoofer: 3000 W
- Voice-coil options: D1, D2
- Cutout size: 13.78 inches
- Basket construction: Cast
American Bass Godfather Series 15" Subwoofer - Dual 1 Ohm is backordered and will ship as soon as it is back in stock.
American Bass Godfather Series 15" Subwoofer - Dual 1 Ohm is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Build high-output bass around the American Bass Godfather Series 15" subwoofer, designed for extreme SPL systems. Its 3000W RMS rating, dual-voice-coil design, and 4” flat-wire wound high-temp coil suit demanding installations with carefully matched amplification.
Pair it with a ported enclosure in the recommended volume range for a trunk setup or dedicated audio installation. The cast basket, multi spider system, and double stitched cone are built for controlled cone movement under heavy use.
Key Features & Benefits
- 3000W RMS power handling: Supports continuous high-power operation when paired with an appropriately matched amplifier.
- Dual voice coil, D1/D2: Offers wiring options for different amplifier loads and installation layouts.
- 4” flat-wire wound high-temp coil: American-made coil construction supports heat management during demanding play.
- Air-cooled bottom plate: Helps dissipate heat during extended high-power use.
- Multi spider system: Adds stiffness and control to cone movement at high output.
- Double stitched cone and cast basket: Reinforced construction supports durability during high excursion.
Technical Specifications
| Specification | Value |
|---|---|
| RMS POWER | 3000W |
| MAX POWER | 6000W |
| IMPEDANCE (OHMS) | D1/D2 |
| SENSITIVITY DB | 87/88.7 |
| MOUNTING DEPTH (IN) | 9.92 |
| CUTOUT SIZE (IN) | 13.78 |
| PORTED BOX (FT 3) | 3 - 3.5 |
| MAGNET SIZE (OZ) | 400 |
| VOICE COIL SIZE | 4 |
| BASKET TYPE | CAST |
| RECOMMENDED AMP (PAIR) | VFL 5K / VFL 6K |
The 3000W RMS rating describes continuous power handling; 6000W is the maximum peak rating. The dual-voice-coil configuration is D1/D2. Recommended amplifier pairs are VFL 5K or VFL 6K.
Why Choose This Product?
This 15-inch driver combines high power handling with construction features intended for demanding SPL builds. Its 400 oz magnet, multi spider system, and air-cooled bottom plate support a design focused on high output and heat management.
The recommended 3 - 3.5 ft³ ported enclosure gives you a defined volume range when planning a system. Match the amplifier and wiring to the selected voice-coil configuration to balance output and control.
Installation & Compatibility Notes
Allow for 9.92 inches of mounting depth and a 13.78-inch cutout. Confirm that the enclosure and mounting location accommodate both measurements before installation.
Use a ported enclosure within the specified 3 - 3.5 ft³ range. Check that your amplifier supports the planned D1/D2 wiring configuration, and match amplifier power to the subwoofer’s ratings.
Frequently Asked Questions
What are the RMS and maximum power ratings?
The subwoofer is rated for 3000W RMS and 6000W maximum power. RMS refers to continuous handling; maximum refers to peak power.
What does D1/D2 impedance mean?
It identifies the dual-voice-coil configuration and its wiring options. Confirm the resulting load is compatible with your amplifier.
What enclosure volume is recommended?
The listed ported-box volume is 3 - 3.5 ft³.
How much mounting space should I allow?
Plan for 9.92 inches of mounting depth and a 13.78-inch cutout.
Explore More
Shop the American Bass Godfather Series 15" subwoofer at 12 Volt Outlet. Want to learn more about American Bass? Explore our American Bass brand profile.
| RMS POWER | 3000W |
| MAX POWER | 6000W |
| IMPEDANCE (OHMS) | D1/D2 |
| SENSITIVITY DB |
87/88.7 |
| MOUNTING DEPTH (IN) |
9.92 |
| CUTOUT SIZE (IN) | 13.78 |
| PORTED BOX (FT3) | 3 - 3.5 |
| MAGNET SIZE (OZ) | 400 |
| VOICE COIL SIZE | 4 |
| BASKET TYPE | CAST |
| RECOMMENDED AMP (PAIR) | VFL 5K / VFL 6K |
Recommended Monoblock Amplifiers
Power-matched options for one subwoofer or one complete loaded enclosure. We aim to include same-brand choices when their ratings qualify.
Loading amplifier suggestions…
Suggestions use 75–125% of the subwoofer’s RMS rating at the wiring load shown. Check wiring, enclosure needs, electrical capacity and installation space. Set gain and filters correctly to avoid overpowering the subwoofer. Buying more than one subwoofer changes the match.
