American Bass HD Series 15" Subwoofer
Key features
- Subwoofer size: 15.0 inches
- RMS power per subwoofer: 2000 W
- Voice-coil options: D1, D2
- Mounting depth: 9.4 inches
- Cutout size: 14.4 inches
- Basket construction: Cast
American Bass HD Series 15" Subwoofer - Dual 1 Ohm is backordered and will ship as soon as it is back in stock.
American Bass HD Series 15" Subwoofer - Dual 1 Ohm is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Build deep, impactful bass into a high-power car audio system with the American Bass HD Series 15" Subwoofer. It handles 2000 W RMS, offers D1 / D2 impedance options, and is recommended for a 3–3.50 ft³ ported enclosure.
Key Features & Benefits
- 2000 W RMS power handling: Suits high-power builds designed for sustained bass output.
- D1 / D2 impedance: Dual-voice-coil options offer flexibility when planning amplifier wiring.
- 3-inch voice coil: Supports heat dissipation and high excursion during demanding passages.
- 350 oz magnet: Helps control cone motion during heavy bass playback.
- Cast basket: Provides a rigid frame to maintain alignment under high power.
Technical Specifications
| Specification | Value |
|---|---|
| RMS Power | 2000W |
| Max Power | 4000W |
| Impedance (Ohms) | D1 / D2 |
| Sensitivity (dB) | 88 |
| Mounting Depth (in) | 9.4 |
| Cutout Size (in) | 14.4 |
| Ported Box (ft³) | 3 – 3.50 |
| Magnet Size (oz) | 350 |
| Voice Coil Size | 3 in |
| Basket Type | Cast |
| Recommended Amp (Pair) | VFL 4K |
Why Choose This Product?
The HD Series 15-inch subwoofer is intended for single- or dual-sub car audio builds that call for substantial bass and a sizable ported enclosure. Its power rating, coil options, and recommended enclosure volume help you plan the system around the subwoofer rather than choosing components by appearance alone.
For a dual-sub setup, the listed amplifier recommendation is the VFL 4K. The enclosure recommendation gives you a starting point for planning a vented bass system around your vehicle and installation space.
Installation & Compatibility Notes
Allow for a 9.4-inch mounting depth and a 14.4-inch cutout. The recommended ported enclosure volume is 3–3.50 ft³. Check your available mounting area and enclosure dimensions before beginning installation.
The subwoofer is listed with D1 / D2 impedance options. Confirm the specific option and your amplifier’s requirements when planning the system wiring.
Frequently Asked Questions
What are the RMS and maximum power ratings?
It is rated for 2000W RMS and 4000W maximum power.
What enclosure volume is recommended?
The recommended ported box volume is 3–3.50 ft³.
How much mounting space does it need?
Plan for a 9.4-inch mounting depth and a 14.4-inch cutout.
Which amplifier is recommended for a pair?
The listed recommended amplifier for a pair is the VFL 4K.
What impedance options are listed?
The impedance options are D1 / D2. Check the specific option when matching the subwoofer to your amplifier.
Explore More
Shop American Bass products at 12 Volt Outlet. Want to learn more about American Bass? Explore our American Bass brand profile.
| RMS POWER | 2000W |
| MAX POWER | 4000W |
| IMPEDANCE (OHMS) | D1 / D2 |
| SENSITIVITY DB |
88 |
| MOUNTING DEPTH (IN) |
9.4 |
| CUTOUT SIZE (IN) |
14.4 |
| PORTED BOX (FT3) |
3 - 3.50 |
| MAGNET SIZE (OZ) | 350 |
| VOICE COIL SIZE | 3 |
| BASKET TYPE | CAST |
| RECOMMENDED AMP (PAIR) | VFL 4K |
