American Bass King Series 15" Subwoofer
Key features
- Subwoofer size: 15.0 inches
- RMS power per subwoofer: 6500 W
- Voice-coil options: D1, D2
- Mounting depth: 12.2 inches
- Cutout size: 13.78 inches
- Voice-coil diameter: 4.5 inches
American Bass King Series 15" Subwoofer - Dual 1 Ohm is backordered and will ship as soon as it is back in stock.
American Bass King Series 15" Subwoofer - Dual 1 Ohm is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The American Bass King Series 15" subwoofer is built for high-output bass in a properly designed ported enclosure. Its 6,500-watt RMS handling, 4.5" voice coil, and 613 oz triple-stacked magnets support demanding playback.
Key Features & Benefits
- Power handling: 6,500 watts RMS and 15,000 watts maximum are listed for continuous and peak power, respectively.
- Dual voice coil: D1 / D2 impedance options offer wiring flexibility for your amplifier and enclosure plan.
- Cast basket: The rigid die-cast design maintains precise geometry.
- Cooling and construction: Direct cooling and a high-temperature flat-wire coil are designed for demanding playback.
- Ported enclosure guidance: The recommended 4 ft³ box volume helps guide enclosure planning.
Technical Specifications
| RMS POWER | 6500 |
| MAX POWER | 15000 |
| IMPEDANCE (OHMS) | D1 / D2 |
| SENSITIVITY DB | 85.7 |
| MOUNTING DEPTH (IN) | 12.2 |
| CUTOUT SIZE (IN) | 13.78 |
| PORTED BOX (FT³) | 4 |
| MAGNET SIZE (OZ) | 613 |
| VOICE COIL SIZE | 4.5" |
| BASKET TYPE | CAST |
| RECOMMENDED AMP (PAIR) | VFL Comp 8K |
Construction includes a regal textured finish die-cast basket, carbon cone foam surround, carbon fiber dust cap, direct cooling system, black anodized T-yoke, double black spider, and 4GA copper push terminals. The 4.5" voice coil is a high-temperature flat-wire design.
Why Choose This Product?
The King Series 15" combines high power handling with a substantial motor assembly and direct cooling. Its D1 / D2 options give you a choice of impedance when planning the system around your amplifier and enclosure.
Installation & Compatibility Notes
Allow for a 12.2-inch mounting depth and a 13.78-inch cutout. The listed ported-box volume is 4 ft³. Check your available space and system requirements before installation.
Frequently Asked Questions
What do the RMS and maximum power ratings mean?
The listed ratings are 6,500 watts RMS continuous power handling and 15,000 watts maximum peak power handling.
What impedance options does this subwoofer offer?
The specification lists D1 / D2. Choose the appropriate option for your amplifier and system wiring plan.
What enclosure volume is recommended?
The listed ported-box volume is 4 ft³.
Which amplifier is recommended for a pair?
The listed recommendation is the VFL Comp 8K for a pair of subwoofers.
Explore More
Shop with 12 Volt Outlet. Want to learn more about American Bass? Explore our American Bass brand profile.
| RMS POWER | 6500 |
| MAX POWER | 15000 |
| IMPEDANCE (OHMS) | D1 / D2 |
| SENSITIVITY DB | 85.7 |
| MOUNTING DEPTH (IN) | 12.2 |
| CUTOUT SIZE (IN) | 13.78 |
| PORTED BOX (FT3) | 4 |
| MAGNET SIZE (OZ) | 613 |
| VOICE COIL SIZE | 4.5" |
| BASKET TYPE | CAST |
| RECOMMENDED AMP (PAIR) | VFL Comp 8K |
Recommended Monoblock Amplifiers
Power-matched options for one subwoofer or one complete loaded enclosure. We aim to include same-brand choices when their ratings qualify.
Loading amplifier suggestions…
Suggestions use 75–125% of the subwoofer’s RMS rating at the wiring load shown. Check wiring, enclosure needs, electrical capacity and installation space. Set gain and filters correctly to avoid overpowering the subwoofer. Buying more than one subwoofer changes the match.
