Deaf Bonce Apocalypse ASA-1500.2 | 1500 Watt 2-channel amplifier
Key features
- Amplifier channels: 2
- RMS per channel at 4 ohms: 550 W
- RMS per channel at 2 ohms: 890 W
- Amplifier class: Class D
- Frequency response: 10 Hz - 20 kHz
- Crossover slope: 12 dB/octave
Deaf Bonce Apocalypse ASA-1500.2 | 1500 Watt 2-channel amplifier is backordered and will ship as soon as it is back in stock.
Deaf Bonce Apocalypse ASA-1500.2 | 1500 Watt 2-channel amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Build a powerful car audio system around the Deaf Bonce Apocalypse ASA-1500.2, a two-channel Class D amplifier with flexible stereo and bridged power options. It delivers up to 1500W RMS per channel at 1 Ohm, or 3020W RMS in bridged mode at 2 Ohm.
Use its simultaneous low-pass and high-pass filters to shape signal for your chosen speaker setup. The 10–20000 Hz frequency response supports a range of car audio applications.
Key Features & Benefits
- Two-channel Class D design: Choose a two-channel setup or a bridged configuration to suit your system plan.
- Multiple RMS ratings: Select among the listed 1, 2, or 4 Ohm stereo power ratings for load-specific planning.
- Bridged output: The amplifier is rated for 3020W RMS at 2 Ohm bridged and 1780W RMS at 4 Ohm bridged.
- Simultaneous LPF and HPF: Use both filters together to tailor crossover settings for connected speakers.
- Signal-to-noise ratio of ≥ 91 dB: This rating describes the amplifier’s signal-to-noise performance.
Technical Specifications
| Model | ASA-1500.2 |
| Class | D |
| Number of the channels | 2 |
| Frequency response | 10-20000 Hz |
| 1 Ohm RMS Power (14.4 V) | 1500W x 2 |
| 2 Ohm RMS Power (14.4 V) | 890 W x 2 |
| 4 Ohm RMS Power (14.4 V) | 550 W x 2 |
| 2 Ohm RMS Power (Bridge) | 3020W x 1 |
| 4 Ohm RMS Power (Bridge) | 1780 W x 1 |
| Minimum permissible load on the channel | 1 Ohm |
| Minimum permissible load in a bridge connection | 2 Ohm |
| The simultaneous operation of LPF and HPF | Yes |
| Low pass filter | 50-1200 / 500-12000 Hz |
| High pass filter | 10-1200 / 100-12000 Hz |
| Crossover | 12 dB/Oct |
| Input terminal | 0 Ga |
| Output terminal | 8 Ga |
| Working voltage | 9 - 15V |
| Signal-to-noise ratio | ≥ 91 dB |
| Size (WxLxH) | 15 x 9.4 x 2.5 inch |
Why Choose This Product?
The ASA-1500.2 gives you distinct power ratings for stereo and bridged use, making load and system planning central to choosing how you use it. Its filter ranges and ability to run LPF and HPF simultaneously add flexibility when setting crossover points for your connected speakers.
For a sub-focused setup, consider the bridged ratings and the 2 Ohm minimum bridged load. For a two-channel setup, compare the speaker load with the per-channel ratings at 1, 2, and 4 Ohm.
Installation & Compatibility Notes
Allow for the amplifier’s 15 x 9.4 x 2.5 inch dimensions when planning its mounting location. Its specified working voltage is 9 - 15V.
Plan the connected load to meet the stated minimums: 1 Ohm per channel or 2 Ohm bridged. The listed input terminal is 0 Ga and the output terminal is 8 Ga. Confirm your system’s load, wiring connections, and available mounting space before installation.
Frequently Asked Questions
How much power does the ASA-1500.2 produce in stereo?
At 14.4 V, its RMS ratings are 1500W x 2 at 1 Ohm, 890 W x 2 at 2 Ohm, and 550 W x 2 at 4 Ohm.
What are the bridged power ratings?
The amplifier is rated for 3020W x 1 RMS at 2 Ohm bridged and 1780 W x 1 RMS at 4 Ohm bridged.
What minimum load should I plan for?
The minimum permissible load is 1 Ohm per channel or 2 Ohm in a bridge connection.
Can the low-pass and high-pass filters operate together?
Yes. The specifications list simultaneous LPF and HPF operation, with a 12 dB/Oct crossover.
