Deaf Bonce Apocalypse ASA-4000.1 | 4000 Watt Power Amplifier
Key features
- Amplifier channels: 1
- RMS output at 4 ohms: 1530.0 W
- RMS output at 2 ohms: 2620 W
- RMS output at 1 ohm: 4000 W
Deaf Bonce Apocalypse ASA-4000.1 | 4000 Watt Power Amplifier is backordered and will ship as soon as it is back in stock.
Deaf Bonce Apocalypse ASA-4000.1 | 4000 Watt Power Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Bring up to 4000 W RMS of bass power to your car audio system with the Deaf Bonce Apocalypse ASA-4000.1 mono Class D amplifier. Its single channel is designed for subwoofer-focused builds, with adjustable filters to help shape the bass signal.
Key Features & Benefits
- 4000 W RMS at 1 Ω: The rating at 14.4 V gives you substantial output for a low-impedance subwoofer load.
- Mono Class D design: One channel concentrates amplification on a dedicated subwoofer setup.
- Adjustable low-pass filter: Set the cutoff from 35–250 Hz to tailor the upper range sent to the woofer.
- Subsonic filter: Adjust from 10–50 Hz to limit very low frequencies.
- Compact dimensions: The 26.6 x 9.4 x 2.5 inch footprint helps with planning a space-conscious installation.
Technical Specifications
| Model | ASA-4000.1 |
| Class | D |
| Number of the channels | 1 |
| Frequency response | 10 - 250 Hz |
| 1 Ohm RMS Power (14.4 V) | 4000 W |
| 1 Ohm RMS Power (12 V) | 3010 W |
| 2 Ohm RMS Power (14.4 V) | 2620 W |
| 4 Ohm RMS Power (14.4 V) | 1530 W |
| Minimum permissible load on the channel | 1 Ohm |
| Low pass filter | 35 - 250 Hz |
| Crossover | 12 dB/Oct |
| Subsonic filter | 10 - 50 Hz |
| Bass frequency adjustment | 35 - 250 Hz |
| Input terminal | 0 Ga |
| Output terminal | 8 Ga |
| Working voltage | 9 - 15 V |
| Signal-to-noise ratio | ≥ 92 dB |
| Size (WxLxH) | 26.6 x 9.4 x 2.5 inch |
Why Choose This Product?
The ASA-4000.1 pairs high-output mono amplification with controls for tailoring the bass range. Its power ratings vary with load impedance and supply voltage, giving you specific figures to consider when matching it to your subwoofer setup.
Installation & Compatibility Notes
Keep the subwoofer load at or above the amplifier’s 1 Ohm minimum. Check your electrical system against the stated 9 - 15 V working range and plan your installation around the listed dimensions and terminal sizes.
Frequently Asked Questions
How much power does the ASA-4000.1 produce at 1 Ohm?
It is rated at 4000 W RMS at 1 Ohm with a 14.4 V supply, and 3010 W RMS at 1 Ohm with a 12 V supply.
Can I use a load below 1 Ohm?
No. The listed minimum permissible load is 1 Ohm.
Can I adjust the bass signal?
Yes. The low-pass filter ranges from 35 - 250 Hz, and the subsonic filter ranges from 10 - 50 Hz. Bass frequency adjustment is listed as 35 - 250 Hz.
How much installation space should I plan for?
The amplifier measures 26.6 x 9.4 x 2.5 inch (WxLxH).
