Audio Ace Jester Series 15" Subwoofer Dual 2 Ohm
Key features
- Subwoofer size: 15.0 inches
- RMS power per subwoofer: 3000 W
- Voice-coil options: D2
- Voice-coil diameter: 3 inches
- Mounting depth: 10.07 inches
- Mounting cutout diameter: 14 inches
Audio Ace Jester Series 15" Subwoofer Dual 2 Ohm is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Build a car audio system around the Audio Ace Jester Series 15" Dual 2 Ohm subwoofer when you want high-output bass in a ported enclosure. Its 3,000 RMS power handling, 300 oz magnet, and dual 2-ohm voice coils are designed for demanding bass systems.
Key Features & Benefits
- 15-inch subwoofer: The large cone size suits systems designed around a 15-inch driver.
- 3,000 RMS power handling: Pair it with a suitable amplifier for a system built to handle sustained high power.
- Dual 2-ohm voice coils: The coil configuration gives you wiring flexibility when planning amplifier matching.
- Die-cast aluminum basket: The rigid basket helps reduce resonance during high-excursion operation.
- 3-inch BACCAW 4-layer coil: Its four-layer construction is designed to handle heat during extended play.
- Four-layer spider suspension: The 10-inch suspension supports cone control across the operating range.
Technical Specifications
| Specification | Value |
|---|---|
| Product | Audio Ace Jester Series 15" subwoofer |
| Voice coils | Dual 2 Ohm |
| RMS power handling | 3,000 RMS |
| Basket | Heavy Duty Die Cast Aluminum Basket |
| Magnet structure | 300 oz magnet |
| Voice coil | 3" BACCAW 4 Layer Coil |
| Suspension | 4 Layer Spider Suspension (10") |
| Cutout | 14.331 in |
| Depth | 10.07 in |
| Recommended enclosure | 3–4 cubic foot ported enclosure |
| Recommended port area | 14–16 square inches per cubic foot |
| Recommended tuning | 28–36 Hz |
| Enclosure design | Optimal in ported 4th and 6th order designs; not recommended for sealed applications |
Why Choose This Product?
The Jester Series combines a high RMS rating with a substantial magnet and a rigid aluminum basket. Its dual 2-ohm coils offer wiring flexibility, while the four-layer coil and spider are designed for demanding playback.
The stated enclosure guidance points to a ported setup, with a 3–4 cubic foot volume and tuning between 28–36 Hz. This makes enclosure planning an important part of choosing this subwoofer.
Installation & Compatibility Notes
Plan for a 14.331 in cutout and 10.07 in mounting depth. The recommended enclosure is ported, with 14–16 square inches of port area per cubic foot; sealed applications are not recommended.
Match the dual 2-ohm voice coils to an amplifier and system configuration that supports your intended wiring and power requirements. Check the available mounting space and enclosure design before installation.
Frequently Asked Questions
What is the RMS power handling?
The subwoofer is rated at 3,000 RMS. Choose an amplifier and system configuration appropriate for that rating.
What impedance are the voice coils?
It has dual 2-ohm voice coils. Confirm that your planned wiring configuration matches your amplifier’s supported load.
What enclosure does this subwoofer call for?
The recommended enclosure is a 3–4 cubic foot ported box, with 14–16 square inches of port area per cubic foot and tuning from 28–36 Hz.
Is it recommended for a sealed enclosure?
No. The product guidance says it is not recommended for sealed applications.
What mounting dimensions should I allow?
Allow for a 14.331 in cutout and 10.07 in depth.
Explore More
Shop with 12 Volt Outlet, and explore the Audio Ace brand profile to learn more about the brand.
Recommended Monoblock Amplifiers
Power-matched options for one subwoofer or one complete loaded enclosure. We aim to include same-brand choices when their ratings qualify.
Loading amplifier suggestions…
Suggestions use 75–125% of the subwoofer’s RMS rating at the wiring load shown. Check wiring, enclosure needs, electrical capacity and installation space. Set gain and filters correctly to avoid overpowering the subwoofer. Buying more than one subwoofer changes the match.
