Audio Code AXC-W82 8" 1,000W RMS Subwoofer D2
Key features
- Subwoofer size: 8.0 inches
- RMS power per subwoofer: 1000 W
- Voice-coil options: D2
- Connections: Push terminals
- Mounting: Eight-hole flange
- Motor ventilation: Rear pole vent
Audio Code AXC-W82 8" 1,000W RMS Subwoofer D2 is backordered and will ship as soon as it is back in stock.
Audio Code AXC-W82 8" 1,000W RMS Subwoofer D2 is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Add high-power bass to a compact system with the Audio Code AXC-W82 8-inch DVC subwoofer. It handles 1,000W RMS and has dual 2-ohm voice coils, giving you 1-ohm or 4-ohm wiring options for a compatible amplifier.
Its 8-inch size suits space-conscious builds, including under-seat enclosures and small sealed boxes, when a larger subwoofer will not fit.
Key Features & Benefits
- 1,000W RMS power handling: Supports high-output system designs in a compact 8-inch format.
- Dual 2-ohm voice coils: Wire the coils in parallel for a 1-ohm final load or in series for 4 ohms.
- Compact cone size: Makes the AXC-W82 an option for installs with limited space for a subwoofer.
- Sealed-enclosure use: A practical choice for compact builds seeking tight, accurate bass.
Technical Specifications
| Specification | Value |
|---|---|
| Brand | Audio Code (Audio Xtreme Code) |
| Model | AXC-W82 |
| Size | 8" |
| Power Handling (RMS) | 1,000W |
| Voice Coil | Dual Voice Coil (DVC) |
| Impedance per Coil | 2 ohms |
| Final Impedance (Parallel) | 1 ohm |
| Final Impedance (Series) | 4 ohms |
- Amplifier pairing: The recommended mono amplifier rating is 750–1,000W RMS at 1 ohm with parallel wiring, or at 4 ohms with series wiring.
- Wiring guidance: The source recommends 4-gauge power and ground wire to the amplifier, and 8 AWG or heavier speaker wire from the amplifier to the subwoofer.
Why Choose This Product?
The AXC-W82 combines 1,000W RMS power handling with an 8-inch footprint and flexible coil wiring. That pairing gives you options when choosing a compatible amplifier and planning a compact subwoofer installation.
Choose the final load to match your amplifier’s supported impedance. Parallel wiring creates a 1-ohm load; series wiring creates a 4-ohm load.
Installation & Compatibility Notes
Plan around the enclosure and available installation space, not just the 8-inch cone size. Check the enclosure’s external dimensions and the mounting location before choosing an under-seat or small-trunk installation.
A sealed enclosure is described as a practical option for this 8-inch subwoofer. Match the coil wiring to an amplifier that supports the resulting 1-ohm or 4-ohm load. The recommended amplifier range is 750–1,000W RMS at the selected load.
Frequently Asked Questions
How can I wire the AXC-W82 for a 1-ohm load?
Wire the two 2-ohm voice coils in parallel to create a 1-ohm final load. Confirm that your amplifier supports 1-ohm operation.
How do I get a 4-ohm final load?
Wire the coils in series. This creates a 4-ohm final load for an amplifier suited to that impedance.
What amplifier rating is recommended?
The recommended pairing is a mono amplifier rated 750–1,000W RMS at 1 ohm or 4 ohms, matching the chosen coil wiring.
What enclosure is suggested?
A sealed enclosure is the practical recommendation for a compact 8-inch build. Check enclosure dimensions against your installation space.
How does the AXC-W82 differ from the AXC-W84?
Both are 8-inch W-series subwoofers rated at 1,000W RMS. The AXC-W82 has dual 2-ohm coils for 1- or 4-ohm wiring; the AXC-W84 has dual 4-ohm coils for 2- or 8-ohm wiring.
