The DC Audio XL SPL 15" Subwoofer is a hand-built USA-made 15-inch driver from the XL SPL line (M4 SPL), engineered for extreme SPL in high-power car audio systems. It’s available in 10, 12, 15, and 18-inch sizes and handles up to 2200W RMS (4400W peak) with a 7–14 day build time.
- Power Handling (RMS/Peak): 2200W RMS / 4400W peak — supports high-output bass performance when paired with a suitable amplifier and enclosure.
- 8-Layer Flat-Wound Hi-Temp Aluminum Voice Coil: 3.0" VC diameter for improved heat dissipation and sustained high-power operation under heavy bass duty.
- Extremely rigid cone & Multilayered foam surround: Non-pressed paper cone and multilayer polymer surround minimize cone flex for controlled excursion and better linearity.
- Cast Aluminum Frame & Hardware: Black cast aluminum frame with rubber mounting gasket, rubber motor boot, and chrome spring-loaded push terminals for durability and reliable installs.
- FEA-Analyzed Motor Assembly: Fully CNC-machined motor assembly optimized via finite element analysis to deliver consistent magnetic performance under load.
- Impedance Options: Dual ohm options (.7/1/1.4/2/4) to match a wide range of amplifiers and wiring configurations.
- 15" Mechanical & Electrical Specs: Mounting Depth 10.25"; Mounting Hole Diameter 14"; Outside Diameter 15.7"; VC Diameter 3.0"; Displacement 0.23 ft³; Sd 791 cm; Vas 66.02 L; Xmax 26 mm; Re 3.98 Ω; Le 3.5 mH; Qts 0.65; Ref SPL @ 1W 87.3 dB.
- Enclosure Recommendations: Sealed box 2.0 ft³; Ported box 3.0 ft³ for the 15" version.
In a real car build, this driver excels in SPL-focused setups where a large, well-tuned enclosure and high-current amplification are available. The combination of sizable Sd and Vas, high Xmax, and robust construction makes it a strong choice for competition-grade bass where accuracy and output are both valued.
| 10" | 12" | 15" | 18" | |
|---|---|---|---|---|
| Mounting Depth | 8.25" | 9" | 10.25" | 11.25" |
| Mounting Hole Diameter | 9.35" | 11" | 14" | 16.75" |
| Outside Driver Diameter | 11" | 12.5" | 15.7" | 18.5" |
| VC Diameter | 3.0" | 3.0" | 3.0" | 3.0" |
| Displacement | .18 ft | .19 ft | .23 ft | .26ft |
| Power Handling rms/peak | 2200/4400 | 2200/4400 | 2200/4400 | 2200/4400 |
| Ohm Options (dual) | .7/1/1.4/2/4 | .7/1/1.4/2/4 | .7/1/1.4/2/4 | .7/1/1.4/2/4 |
| Sd | 324 cm | 494 cm | 791Â cm | 1159Â cm |
| Vas | 12.42Â L | 25.77Â L | 66.02Â L | 144.36 L |
| Cms | 0.085 Mm/n | 0.08 Mm/n | 0.07 Mm/n | 0.07 Mm/n |
| Mms | 171.77Â g | 213.7 g | 306.7Â g | 346.07Â g |
| Fs | 41.7Hz | 38.5 Hz | 34.3 Hz | 32.3 Hz |
| Bl | 22.73Â N/A | 22.73Â N/A | 22.73Â N/A | 22.73Â N/A |
| Re | 3.98Â Ohm | 3.98 Ohm | 3.98 Ohm | 3.98 Ohm |
| Le | 5.2Â mH | 5.2Â mH | 3.5 mH | 3.5 mH |
| Qms | 11.24 |
12.92 |
8.18 | 8.32 |
| Qes | 0.35 |
0.403 |
0.706 | 0.718 |
| Qts |
0.34 | 0.391 |
0.65 | 0.661 |
| Xmax | 26mm | 26mm | 26mm | 26mm |
| Ref SPL @1 watt | 85.9 db | 87.5 db | 87.3 db | 90.4 db |
| Suggest Sealed Box | .75 ft | 1.0 ft | 2.0 ft | 3.5 ft |
| Suggested Ported Box | 1.0 ft | 1.50Â ft | 3.0 ft | 5.5 ft |
