Deaf Bonce Apocalypse ASA 2500.2 2 Channel Full Range Amplifier
Key features
- Amplifier channels: 2
- RMS per channel at 4 ohms: 990 W
- RMS per channel at 2 ohms: 1630 W
- Amplifier class: Class D
- Frequency response: 10 Hz - 20 kHz
- Crossover slope: 12 dB/octave
Deaf Bonce Apocalypse ASA 2500.2 2 Channel Full Range Amplifier is backordered and will ship as soon as it is back in stock.
Deaf Bonce Apocalypse ASA 2500.2 2 Channel Full Range Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The Deaf Bonce Apocalypse ASA 2500.2 is a two-channel Class D car amplifier for high-output stereo systems or bridged subwoofer setups. Its power ratings support several speaker-load options, while adjustable high-pass and low-pass filters help tailor the signal to your system.
Key Features & Benefits
- Stereo or bridged operation: Use two channels or bridge the amplifier for a single-channel output.
- Multiple power ratings: Choose among the listed 1-, 2-, and 4-ohm loads to match your system design.
- Adjustable filtering: LPF and HPF can operate simultaneously for flexible speaker integration.
- Wide filter ranges: Set the listed high-pass and low-pass ranges to shape the signal for connected speakers.
- High-current terminals: The 0 Ga input and 8 Ga output terminals accommodate the specified wiring sizes.
Technical Specifications
| Model | ASA-2500.2 |
| Class | D |
| Number of the channels | 2 |
| Frequency response | 10-20000 Hz |
| 1 Ohm RMS Power (14.4 V) | 2500W x 2 |
| 2 Ohm RMS Power (14.4 V) | 1630 W x 2 |
| 4 Ohm RMS Power (14.4 V) | 990 W x 2 |
| 2 Ohm RMS Power (Bridge) | 5000W x 1 |
| 4 Ohm RMS Power (Bridge) | 3260 W x 1 |
| Minimum permissible load on the channel | 1 Ohm |
| Minimum permissible load in a bridge connection | 2 Ohm |
| The simultaneous operation of LPF and HPF | Yes |
| Low pass filter | 500 - 12000 Hz |
| High pass filter | 100 - 12000 Hz |
| Crossover | 12 dB/Oct |
| Input terminal | 0 Ga |
| Output terminal | 8 Ga |
| Working voltage | 9 - 16V |
| Signal-to-noise ratio | ≥ 95 dB |
| Size (WxLxH) | 19.17 x 9.4 x 2.5 inch |
Why Choose This Product?
The ASA 2500.2 gives you options for building a two-channel system or running a bridged configuration. Its listed power ratings and minimum load limits help you plan around the speakers or subwoofer in your system.
With simultaneous LPF and HPF operation, you can set both filter types without relying on a separate amplifier for that function. The 19.17 x 9.4 x 2.5-inch dimensions also give you specific measurements to consider when planning a mounting location.
Installation & Compatibility Notes
Match the connected load to the amplifier’s minimum permissible rating: 1 Ohm per channel or 2 Ohm when bridged. Check the power rating for the selected load and configuration before connecting speakers.
Plan for the stated 9 - 16V working voltage and the 0 Ga input and 8 Ga output terminals. Measure your intended mounting space against the listed dimensions before installation.
Frequently Asked Questions
What is the rated power at 2 Ohms in two-channel operation?
The specification table lists 1630 W x 2 RMS at 2 Ohms and 14.4 V.
Can the ASA 2500.2 be bridged?
Yes. The table lists bridged RMS ratings at 2 Ohms and 4 Ohms. The minimum permissible bridged load is 2 Ohms.
Can the LPF and HPF operate at the same time?
Yes. Simultaneous LPF and HPF operation is listed as supported.
What are the amplifier’s dimensions?
Its listed size is 19.17 x 9.4 x 2.5 inch (WxLxH).
What working voltage does it support?
The listed working voltage is 9 - 16V.
