Deaf Bonce Apocalypse ATOM 7.5K PRO | 7500 Watt Power Amplifier
Key features
- Amplifier channels: 1
- RMS output at 4 ohms: 2500.0 W
- RMS output at 2 ohms: 4150 W
- RMS output at 1 ohm: 7500 W
Deaf Bonce Apocalypse ATOM 7.5K PRO | 7500 Watt Power Amplifier is backordered and will ship as soon as it is back in stock.
Deaf Bonce Apocalypse ATOM 7.5K PRO | 7500 Watt Power Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Give your subwoofer system powerful, adjustable bass with the Deaf Bonce Apocalypse ATOM 7.5K PRO mono Class D amplifier. It delivers 7500 W RMS at 1 Ohm and 14.4 V, with filter controls to shape the sub-bass response for your setup.
Use it as a dedicated subwoofer amplifier in a high-power car audio system. Its compact 15 x 8.6 x 2.6 inch size can help when planning an installation with limited space.
Key Features & Benefits
- High RMS output: Choose from ratings up to 7500 W RMS at 1 Ohm and 14.4 V.
- Multiple impedance ratings: Power ratings are listed at 1, 2, and 4 Ohms for different subwoofer configurations.
- Adjustable low-pass filter: Set the cutoff from 40 - 250 Hz to shape the upper range sent to your subwoofer.
- Subsonic filter: Adjust from 10 - 50 Hz to roll off ultra-low frequencies.
- Bass frequency adjustment: The 35 - 90 Hz range lets you tune bass response to your music and enclosure.
- Vehicle voltage range: The stated 9 - 15 V working range covers typical vehicle electrical system voltages.
Technical Specifications
| Model | ATOM 7.5K PRO |
| Class | D |
| Number of the channels | 1 |
| Frequency response | 10 - 250 Hz |
| 1 Ohm RMS Power (14.4 V) | 7500 W |
| 1 Ohm RMS Power (12 V) | 5810 W |
| 2 Ohm RMS Power (14.4 V) | 4150 W |
| 4 Ohm RMS Power (14.4 V) | 2500 W |
| Minimum permissible load on the channel | 1 Ohm |
| Low pass filter | 40 - 250 Hz |
| Crossover | 12 dB/Oct |
| Subsonic filter | 10 - 50 Hz |
| Bass frequency adjustment | 35 - 90 Hz |
| Input terminal | 0 Ga |
| Output terminal | 4 Ga |
| Working voltage | 9 - 15 V |
| Signal-to-noise ratio | ��� 86 dB |
| Size (WxLxH) | 15 x 8.6 x 2.6 inch |
Why Choose This Product?
The ATOM 7.5K PRO combines a single-channel Class D design with substantial RMS output and adjustable bass controls. Its ratings at several impedance loads help you compare its output with your planned subwoofer configuration.
The low-pass, subsonic, and bass frequency adjustments give you separate controls for shaping the subwoofer signal. This makes the amplifier a considered option when you want to tailor bass response to your enclosure and music.
Installation & Compatibility Notes
Check that your subwoofer configuration meets the amplifier’s 1 Ohm minimum permissible load. Match the system design to the listed power ratings for the applicable impedance and supply voltage.
Plan installation space around the stated 15 x 8.6 x 2.6 inch dimensions. The listed input and output terminal sizes are 0 Ga and 4 Ga, respectively; confirm your wiring and installation requirements before setup.
Frequently Asked Questions
How much RMS power does the ATOM 7.5K PRO produce?
It is rated at 7500 W RMS at 1 Ohm and 14.4 V. The table also lists 5810 W RMS at 1 Ohm and 12 V.
What is the minimum permitted load?
The minimum permissible channel load is 1 Ohm. Check your complete subwoofer configuration against this limit.
What filter adjustments are available?
The low-pass filter adjusts from 40 - 250 Hz, the subsonic filter from 10 - 50 Hz, and bass frequency adjustment from 35 - 90 Hz.
What are the amplifier’s dimensions?
Its listed size is 15 x 8.6 x 2.6 inch (WxLxH). Compare these measurements with the space planned for installation.
What vehicle voltage range is listed?
The working voltage is 9 - 15 V. RMS power ratings vary by supply voltage and impedance, so refer to the specification table for the matching rating.
