Deaf Bonce Apocalypse DB-SA252 D1/D2 12" Subwoofer
Key features
- Subwoofer size: 12.0 inches
- RMS power per subwoofer: 1000 W
- Voice-coil options: D1, D2
- Voice-coil diameter: 2.5 in
- Xmax: 15 mm
- Mounting depth: 167.9 mm
Deaf Bonce Apocalypse DB-SA252 D1/D2 12" Subwoofer - Dual 1 Ohm is backordered and will ship as soon as it is back in stock.
Deaf Bonce Apocalypse DB-SA252 D1/D2 12" Subwoofer - Dual 1 Ohm is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The Deaf Bonce Apocalypse DB-SA252 D1/D2 12-inch subwoofer gives your car audio system a 1000 W RMS driver for bass-focused builds. Choose between dual 2+2 Ohm and 1+1 Ohm coil options to match your amplifier and system plan.
Key Features & Benefits
- Power handling: 1000 W RMS and 2000 W MAX ratings suit high-power system planning.
- Dual voice coils: The 2+2 / 1+1 Ohm options provide flexibility when matching the subwoofer to an amplifier.
- 12-inch paper cone: The paper cone and foam surround are designed for controlled bass response and linear excursion.
- 15.00 mm Xmax: Linear excursion supports strong cone movement at demanding listening levels.
- Aluminum frame: The rigid frame supports the driver while keeping its listed frame material clear for installation planning.
- Enclosure data: Fs, Qts, and Vas provide useful starting points when designing a sealed or vented enclosure.
Technical Specifications
| Model | DB-SA252D2 / DB-SA252D1 |
| Type | Subwoofer |
| Size | 12 inch |
| Voice coil size | 2.50 inch |
| Cone | Paper |
| Magnet | Ferrite |
| Voice coil wire | Copper |
| Surround | Foam |
| RMS Power | 1000 W |
| MAX Power | 2000 W |
| Frame | Alu |
| Impedance | 2+2 / 1+1 Ohm |
| SPL | 85.00 / 84.70 dB |
| Fs | 32.57 / 32.10 Hz |
| Qts | 0.38 / 0.36 |
| BL | 23.22 / 22.74 |
| Vas | 24.91 / 24.72 L |
| Xmax | 15.00 / 15.00 mm |
| Mounting depth | 6.61 inch |
| Cut-out dimension | 11.00 inch |
| Gross weight | 26.57 lb (12.05 kg) |
Why Choose This Product?
This subwoofer combines substantial continuous power handling with dual-impedance options, giving you useful flexibility when planning a high-output car audio system. Its Fs, Qts, and Vas figures help guide enclosure design, while the 12-inch size suits builds planned around that driver format.
The listed 2000 W MAX rating describes peak handling; use the 1000 W RMS rating when comparing continuous power requirements. The two model variants have different listed SPL, Fs, Qts, BL, and Vas values, so use the figures that correspond to your selected version.
Installation & Compatibility Notes
Allow for the 6.61-inch mounting depth and 11.00-inch cut-out dimension when checking your enclosure. Confirm the available space and opening before installation.
Match the selected coil impedance to your amplifier’s supported load and plan the enclosure using the specifications for the chosen variant. The product details list sealed and vented designs as enclosure options, but do not specify a recommended enclosure volume or tuning frequency.
Frequently Asked Questions
What are the power ratings for the DB-SA252?
It is rated at 1000 W RMS and 2000 W MAX. Use the RMS rating when assessing continuous amplifier output.
What impedance options are listed?
The specifications list dual-coil options of 2+2 Ohm and 1+1 Ohm. Match the selected version and wiring load to your amplifier’s supported impedance.
How much mounting space does it require?
Allow for a 6.61-inch mounting depth and an 11.00-inch cut-out.
Can I use this subwoofer in a sealed or vented enclosure?
The product details describe both enclosure types as options. Use the listed Fs, Qts, and Vas figures for the selected variant when planning the enclosure.
