Deaf Bonce Apocalypse DB-SA272 D1/D2 12" Subwoofer
Key features
- Subwoofer size: 12.0 inches
- RMS power per subwoofer: 1500 W
- Voice-coil options: D1, D2
- Voice-coil diameter: 2.75 in
- Xmax: 18 mm
- Mounting depth: 179.5 mm
Deaf Bonce Apocalypse DB-SA272 D1/D2 12" Subwoofer - Dual 1 Ohm is backordered and will ship as soon as it is back in stock.
Deaf Bonce Apocalypse DB-SA272 D1/D2 12" Subwoofer - Dual 1 Ohm is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The Deaf Bonce Apocalypse DB-SA272 D1/D2 is a 12-inch car subwoofer rated at 1500 W RMS and 3000 W maximum. Its paper cone, foam surround, ferrite magnet, and aluminum frame bring together the specified components for a high-power car audio build.
Choose between the DB-SA272D1 and DB-SA272D2 models, with listed impedance options of 1+1 Ohm and 2+2 Ohm. Check the exact model and impedance against your amplifier and installation plans before choosing.
Key Features & Benefits
- Power ratings: 1500 W RMS and 3000 W maximum describe its stated power handling.
- Two model options: The DB-SA272D1 and DB-SA272D2 give you two listed impedance choices to consider when planning an amplifier pairing.
- 2.75-inch voice coil: The stated voice coil size is a key detail when comparing subwoofers for a high-power system.
- Paper cone and foam surround: These specified components define the subwoofer’s moving assembly.
- Aluminum frame: The frame material is a useful consideration when comparing subwoofer construction.
- Installation dimensions: The 7.07-inch mounting depth and 11.00-inch cut-out dimension help you assess available mounting space.
Technical Specifications
| Model | DB-SA272D2 / DB-SA272D1 |
| Type | Subwoofer |
| Size | 12 inch |
| Voice coil size | 2.75 inch |
| Cone | Paper |
| Magnet | Ferrite |
| Voice coil wire | CCAW |
| Surround | Foam |
| RMS Power | 1500 W |
| MAX Power | 3000 W |
| Frame | Alu |
| Impedance | 2+2 / 1+1 Ohm |
| SPL | 86.20 / 86.00 dB |
| Fs | 31.12 / 30.63 Hz |
| Qts | 0.36 / 0.34 |
| BL | 20.83 / 20.10 |
| Vas | 30.74 / 29.52 L |
| Xmax | 18.00 / 18.00 mm |
| Mounting depth | 7.07 inch |
| Cut-out dimension | 11.00 inch |
| Gross weight | 30.64 lb (13.90 kg) |
Why Choose This Product?
This Apocalypse subwoofer gives you specific power, impedance, and driver measurements to consider when planning a car audio system. Its listed Thiele/Small values—including Fs, Qts, BL, and Vas—can help inform enclosure and system planning alongside the dimensions and impedance.
Use the model and impedance details to narrow your choice, then plan the enclosure and amplifier around the selected version. The published SPL values are listed as 86.20 / 86.00 dB, offering another point of comparison between the specifications.
Installation & Compatibility Notes
Allow for a 7.07-inch mounting depth and an 11.00-inch cut-out, and check the available space in your intended location before installation. Confirm your amplifier can support the impedance of the exact model you select. Consider the listed RMS rating when planning system power; the 3000 W figure is the maximum power rating, not the RMS rating.
Frequently Asked Questions
What are the power ratings?
The subwoofer is rated at 1500 W RMS and 3000 W maximum. Use the RMS figure when comparing continuous amplifier output.
What impedance options are listed?
The specifications list 2+2 / 1+1 Ohm for the DB-SA272D2 / DB-SA272D1 models. Confirm the selected model’s impedance when matching it to an amplifier.
How much mounting space should I allow?
Check for 7.07 inches of mounting depth and an 11.00-inch cut-out dimension at your planned installation location.
What cone and surround materials does it use?
The cone is paper, and the surround is foam.
