The Diamond Audio MICRO88U provides amplifier power for a motorcycle audio installation. Match the speaker load and channel configuration to the ratings below before installation.
Features and specifications
- Eight-channel full-range Class D amplifier.
- RMS output: 100 watts × 8 at 2 ohms; 75 watts × 8 at 4 ohms.
- Input sensitivity: 0.2–10 volts.
- Channels 1–4: fixed 70 Hz high-pass filter with 12 dB/octave slope.
- Channels 5–8: 40–400 Hz crossover with 12 dB/octave slope.
- Frequency response: 10 Hz–33 kHz.
- Selectable two-channel or eight-channel input mode.
- Dimensions: 11.44 × 4.0 × 1.6 inches (290.5 × 103 × 40.6 mm), as listed by Diamond Audio.
- RCA input and speaker-output harness kits included.
