DS18 EXL-X8.4D EXL-X 8" Subwoofer 1200 Watts Dvc 4-Ohms
Key features
- Subwoofer size: 8.0 inches
- RMS power per subwoofer: 600 W
- Voice-coil options: D4
- Frequency response: 38 Hz–1 kHz
- Voice-coil diameter: 2.5 inches
- Magnet material: Ferrite
DS18 EXL-X8.4D EXL-X 8" Subwoofer 1200 Watts Dvc 4-Ohms is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Bring powerful low-frequency sound to your car audio system with the DS18 EXL-X8.4D 8-inch subwoofer. Its dual 4-ohm voice coils offer wiring flexibility, while its 600W RMS and 1200W maximum power ratings suit installations built around substantial bass output.
Key Features & Benefits
- Dual 4-ohm voice coils: Choose a wiring configuration that matches your amplifier setup.
- 600W RMS power handling: Supports sustained power when paired with suitable amplification.
- Paper and glass-fiber diaphragm: Combines stiffness and light weight for bass reproduction.
- Aluminum basket: Provides a rigid chassis, finished in glossy red.
- Sealed or ported enclosure options: Choose the recommended enclosure style that suits your bass goals.
- Ferrite magnet: Provides the subwoofer’s magnetic structure for car audio use.
Technical Specifications
| Specification | Value |
|---|---|
| Nominal Diameter | 8" (203.2mm) |
| Nominal Impedance | 4+4 ohms |
| RMS Power Handling | 600W |
| Maximum Power Handling | 1200W |
| Sensitivity | 89dB (1W/1m) |
| Frequency Response | 38Hz–1kHz |
| Voice Coil Diameter | 2.5" (63.5mm) |
| Voice Coil Former Material | Black Aluminum |
| Winding Material | SV |
| Diaphragm Material | Non-Pressed Paper + Glass Fiber |
| Dust Cap Material | Fiberglass |
| Surround Material | Foam |
| Basket Material | Aluminum |
| Basket Color/Finish | Glossy Red |
| Magnet Material | Ferrite |
| Weight | 130 oz |
| Recommended Sealed Enclosure Internal Volume | 0.3 ft³ |
| Recommended Ported Enclosure Internal Volume | 0.5 ft³ |
| Port Size | 1" x 8" x 10.56" (W x H x L) |
| Port Tuning Frequency | 55 Hz |
| Overall Diameter | 8.58" (218mm) |
| Overall Depth | 6.61" (168mm) |
| Front Mount Baffle Cutout | 7.36" (187mm) |
| Mounting Depth | 5.51" (140mm) |
Why Choose This Product?
The EXL-X8.4D gives you a choice between sealed and ported enclosure designs. A sealed enclosure is specified for a 0.3 ft³ internal volume, while the 0.5 ft³ ported recommendation includes a defined port size and tuning frequency.
Its material choices are specific to the driver: a black aluminum voice coil former, fiberglass dust cap, foam surround, and aluminum basket. The glossy red basket also adds a distinctive visual detail to an installation where the subwoofer is visible.
Installation & Compatibility Notes
Check the enclosure space and mounting surface against the listed overall diameter, overall depth, baffle cutout, and mounting depth before installation. These measurements describe different parts of the fit and should not be treated as interchangeable.
Match the dual 4-ohm voice coils to an amplifier setup that supports the resulting load. Confirm the enclosure’s internal volume and, for a ported design, the stated port dimensions and tuning frequency.
Frequently Asked Questions
What does the 1200W maximum rating mean?
It is the maximum power handling rating. The listed RMS power handling is 600W.
What impedance does the EXL-X8.4D have?
It has dual 4-ohm voice coils, listed as 4+4 ohms. Confirm the wiring configuration and resulting load are suitable for your amplifier.
Which enclosure sizes are recommended?
The listed internal volumes are 0.3 ft³ for a sealed enclosure and 0.5 ft³ for a ported enclosure. The ported recommendation specifies a 1" x 8" x 10.56" port tuned to 55 Hz.
What measurements should I check before mounting it?
Compare the 8.58" overall diameter, 6.61" overall depth, 7.36" front-mount baffle cutout, and 5.51" mounting depth with your installation space.
What frequency range is listed?
The specified frequency response is 38Hz–1kHz.
