DS18 | SKU:
NXL-N2
DS18 NXL-N2 2-Channel Marine Amplifier
Regular price
$324.95
Unit price
Shipping calculated at checkout.
Key features
- 2-channel Class D amplification
- 150W RMS per channel at 2 ohms; 100W RMS per channel at 4 ohms
- Compact 200 × 93.4 × 39.8mm chassis
- Four-layer circuit board
- Model: NXL-N2
- Number of Channels: 2
DS18 NXL-N2 2-Channel Marine Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
The DS18 NXL-N2 is a compact two-channel marine and powersports amplifier with full-range operation. Its selectable low-pass, full-range and high-pass modes allow different speaker applications in a small installation space.
RMS output at 14.4 volts
- 2 × 100 watts at 4 ohms
- 2 × 150 watts at 2 ohms
- 1 × 300 watts bridged at 4 ohms
Installation considerations
Plan the speaker load and crossover mode before connecting the system. DS18 specifically states that this amplifier is not for submerged use. Mount it accordingly and allow space around the housing for wiring and service access; marine application does not mean it should be installed underwater.
