FOX BOX 1999–2006 GM 1500 Crew Cab Single 10-Inch Vented Subwoofer Enclosure
Key features
- Single 10-inch vented chamber with 35 Hz tuning.
- Side-exit vent positioned toward the truck corner.
- Two front standoffs provide separation from the hard seat back.
- Black LINE-X coating is durable and easy to clean.
FOX BOX 1999–2006 GM 1500 Crew Cab Single 10-Inch Vented Subwoofer Enclosure - NO ADAPTER RING is backordered and will ship as soon as it is back in stock.
FOX BOX 1999–2006 GM 1500 Crew Cab Single 10-Inch Vented Subwoofer Enclosure - NO ADAPTER RING is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
This Fox Box enclosure is supplied empty and is shaped for the vehicle application listed in the specifications. Its physical layout is the mounting layout listed below.
This is an empty enclosure. Subwoofers, amplifiers and wiring are not included.
Key Features & Benefits
- Single 10-inch vented chamber with 35 Hz tuning.
- Side-exit vent positioned toward the truck corner.
- Two front standoffs provide separation from the hard seat back.
- Black LINE-X coating is durable and easy to clean.
Technical Specifications
| Model | GM-CC-110-V-99 |
|---|---|
| Vehicle application | 1999–2006 GM 1500 Crew Cab only |
| Excluded models | GM 2500 and 3500 |
| Enclosure type | Vented; side-exit vent |
| Subwoofer configuration | One 10-inch mounting openings |
| Mounting cutout | 9.15 inches |
| Mounting depth | 5.25 inches |
| Maximum magnet diameter | 7 inches |
| Internal air volume | 1.4 cu ft |
| Tuning frequency | 35 Hz |
| Finish | Black LINE-X spray-on bed-liner coating |
Why Choose This Product?
This empty enclosure has the vehicle-specific shape and mounting layout listed above. Physical fit limits include mounting depth: 5.25 inches. Review the interior-clearance and installation restrictions before ordering.
Installation & Compatibility Notes
- Fits the GM 1500 Crew Cab only; 2500 and 3500 trucks are excluded.
- Subwoofers with larger frames may require the installer to trim the mounting opening. Compare the cutout, depth and magnet dimensions before selecting a subwoofer.
- Plastic vent tubes in the rear corners, if present, must be removed.
- Floor flaps attached to the rear seat may require removal. This can involve metal cutting; use a qualified installer if you do not have the appropriate tools and experience.
Frequently Asked Questions
Can I use this in a 2500 or 3500?
No. The listed fitment is limited to 1999–2006 GM 1500 Crew Cab trucks.
Will installation require modifications?
It may. Corner vent tubes must be removed if present, and rear-seat floor flaps may also need removal.
How much mounting depth is available?
The listed mounting depth is 5.25 inches, with a maximum magnet diameter of 7 inches.
