FOX BOX 2004–2014 Colorado & Canyon Crew Cab Single 10-Inch Rear Console Sub Box
Key features
- Rear-console enclosure layout for the specified Colorado/Canyon Crew Cabs.
- Single 10-inch opening with a 9.125-inch cutout.
- 8-inch mounting depth and 1.75-inch floor clearance.
- Screw-mounted spring terminal for the speaker connection.
FOX BOX 2004–2014 Colorado & Canyon Crew Cab Single 10-Inch Rear Console Sub Box is backordered and will ship as soon as it is back in stock.
FOX BOX 2004–2014 Colorado & Canyon Crew Cab Single 10-Inch Rear Console Sub Box is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
This Fox Box enclosure is supplied empty and is shaped for the vehicle application listed in the specifications. Its physical layout is the mounting layout listed below.
This is an empty enclosure. Subwoofers, amplifiers and wiring are not included.
Key Features & Benefits
- Rear-console enclosure layout for the specified Colorado/Canyon Crew Cabs.
- Single 10-inch opening with a 9.125-inch cutout.
- 8-inch mounting depth and 1.75-inch floor clearance.
- Screw-mounted spring terminal for the speaker connection.
Technical Specifications
| Variant SKU | COL-CC-110 |
|---|---|
| Additional description identifier | COLORADO-110 |
| Vehicle application | 2004–2014 Colorado/Canyon Crew Cab |
| Subwoofer configuration | One 10-inch mounting openings |
| Mounting cutout | 9.125 inches |
| Mounting depth | 8 inches |
| Internal air volume | 0.68 cu ft |
| Floor clearance | 1.75 inches |
| Connector | Screw-mounted spring terminal |
Why Choose This Product?
This empty enclosure has the vehicle-specific shape and mounting layout listed above. Physical fit limits include mounting depth: 8 inches. Review the interior-clearance and installation restrictions before ordering.
Installation & Compatibility Notes
- Does not fit Extended Cab trucks.
- Confirm the Crew Cab layout and intended rear-console installation location before ordering.
- Check the subwoofer’s recommended enclosure volume, cutout and mounting depth. No magnet-diameter limit is provided in the source specifications.
Frequently Asked Questions
Will it fit an Extended Cab?
No. The stated application is the 2004–2014 Colorado/Canyon Crew Cab.
What is the mounting depth?
The listed depth is 8 inches.
How does the speaker wire connect?
The enclosure uses a screw-mounted spring terminal.
