FOX BOX 2019–2025 Ram 1500 Crew Cab Dual 12-Inch Vented Subwoofer Enclosure V2
Key features
- Dual 12-inch vented layout with 3.5 cubic feet of shared air volume.
- 33 Hz vent tuning.
- Included 5/8-inch seat-lift kit.
- In-floor Ram storage remains accessible.
- Optional pair of 12-to-10-inch adapter rings; black bed-liner finish.
FOX BOX 2019–2025 Ram 1500 Crew Cab Dual 12-Inch Vented Subwoofer Enclosure V2 - NO ADAPTER RING is backordered and will ship as soon as it is back in stock.
FOX BOX 2019–2025 Ram 1500 Crew Cab Dual 12-Inch Vented Subwoofer Enclosure V2 - NO ADAPTER RING is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
This Fox Box enclosure is supplied empty and is shaped for the vehicle application listed in the specifications. Its physical layout is the mounting layout listed below.
This is an empty enclosure. Subwoofers, amplifiers and wiring are not included.
Key Features & Benefits
- Dual 12-inch vented layout with 3.5 cubic feet of shared air volume.
- 33 Hz vent tuning.
- Included 5/8-inch seat-lift kit.
- In-floor Ram storage remains accessible.
- Optional pair of 12-to-10-inch adapter rings; black bed-liner finish.
Technical Specifications
| Model | DCC-212-V-19 |
|---|---|
| Version | V2 |
| Vehicle application | 2019–2025 fifth-generation Ram 1500 Crew Cab |
| Excluded applications | Classic body; Quad Cab; 2500/3500 |
| Enclosure type | Vented; undivided |
| Subwoofer configuration | Two 12-inch subwoofers; optional 10-inch adapter rings |
| Mounting cutout | 11.15 inches |
| Mounting depth | 7 inches with a 7-inch-diameter magnet |
| Internal air volume | 3.5 cu ft shared |
| Tuning frequency | 33 Hz |
| Required seat lift | 5/8 inch; kit included |
| Finish | Black spray-on bed-liner coating |
Why Choose This Product?
This empty enclosure has the vehicle-specific shape and mounting layout listed above. Physical fit limits include mounting depth: 7 inches with a 7-inch-diameter magnet. Review the interior-clearance and installation restrictions before ordering.
Installation & Compatibility Notes
- Does not fit Classic-body trucks, Quad Cab models, or Ram 2500/3500 trucks.
- This listing covers the explicitly specified 2019–2025 model years. Later model-year compatibility is not established here.
- The included 5/8-inch seat-lift kit is required. The front edge of the rear seat is slightly elevated.
- Compatible reclining seats must be slid fully rearward, and reclining is no longer possible after installation.
- In-floor Ram storage is not blocked.
- Floor mats extending under the rear seats must be trimmed or removed.
- Subwoofers with larger frames may require the installer to trim the mounting opening. Compare the cutout, depth and magnet dimensions before selecting a subwoofer.
Frequently Asked Questions
Does it fit a Ram Classic or Quad Cab?
No. It is for the specified fifth-generation Ram 1500 Crew Cab, not Classic, Quad Cab, 2500 or 3500 applications.
Can I still recline the rear seat?
No. Reclining seats must be slid all the way back, and the recline function is no longer usable with this enclosure installed.
Will it block the in-floor storage?
The source states that the in-floor Ram storage is not blocked.
Explore More
Compare more FOX BOX enclosures and accessories at 12 Volt Outlet.
Gallery note: Installation examples show vehicles and other equipment that are not included. Only the empty enclosure or accessory described in this listing is included.
