FOX BOX 2019+ Ram 1500 Crew Cab Single 12-Inch Vented Subwoofer Enclosure
Key features
- Single 12-inch vented layout with 1.9 cubic feet of air volume.
- 34 Hz tuning and 7-inch mounting depth with a 7-inch magnet.
- Required 5/8-inch seat-lift kit included.
- In-floor Ram storage remains unblocked.
- Optional 12-to-10-inch adapter configuration and black bed-liner finish.
FOX BOX 2019+ Ram 1500 Crew Cab Single 12-Inch Vented Subwoofer Enclosure - 12"- NO ADAPTER NEEDED is backordered and will ship as soon as it is back in stock.
FOX BOX 2019+ Ram 1500 Crew Cab Single 12-Inch Vented Subwoofer Enclosure - 12"- NO ADAPTER NEEDED is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
This Fox Box enclosure is supplied empty and is shaped for the vehicle application listed in the specifications. Its physical layout is the mounting layout listed below.
This is an empty enclosure. Subwoofers, amplifiers and wiring are not included.
Key Features & Benefits
- Single 12-inch vented layout with 1.9 cubic feet of air volume.
- 34 Hz tuning and 7-inch mounting depth with a 7-inch magnet.
- Required 5/8-inch seat-lift kit included.
- In-floor Ram storage remains unblocked.
- Optional 12-to-10-inch adapter configuration and black bed-liner finish.
Technical Specifications
| Model | DCC-112-V-19 |
|---|---|
| Vehicle application | 2019 and newer fifth-generation Ram 1500 Crew Cab |
| Excluded applications | Classic body; Quad Cab; 2500/3500 |
| Enclosure type | Vented |
| Subwoofer configuration | One 12-inch subwoofer; optional 10-inch adapter |
| Mounting cutout | 11.15 inches |
| Mounting depth | 7 inches with a 7-inch-diameter magnet |
| Internal air volume | 1.9 cu ft |
| Tuning frequency | 34 Hz |
| Required seat lift | 5/8 inch; kit included |
| Finish | Black spray-on bed-liner coating |
Why Choose This Product?
This empty enclosure has the vehicle-specific shape and mounting layout listed above. Physical fit limits include mounting depth: 7 inches with a 7-inch-diameter magnet. Review the interior-clearance and installation restrictions before ordering.
Installation & Compatibility Notes
- Does not fit Classic-body trucks, Quad Cab models, or Ram 2500/3500 trucks.
- The included 5/8-inch seat-lift kit is required for proper fit.
- The box can be used with reclining seats, but full recline is no longer possible.
- In-floor Ram storage is not blocked.
- Floor mats extending beneath the rear seats must be trimmed or removed.
- Check the chosen driver’s cutout, depth, magnet and enclosure requirements; select the adapter option for a compatible 10-inch subwoofer.
Frequently Asked Questions
Will it fit a Quad Cab or Classic?
No. The application is limited to the specified fifth-generation Ram 1500 Crew Cab.
Can the rear seats still recline?
The source states that the enclosure works with reclining seats, but full recline is no longer possible.
Is a seat lift necessary?
Yes. The included 5/8-inch seat-lift kit is required.
