FOX BOX Ram Quad & Crew Cab Dual 12-Inch Vented Subwoofer Enclosure
Key features
- Dual 12-inch vented layout tuned to 35 Hz.
- Two-piece enclosure design.
- Included 1.25-inch seat-lift kit for the required installation clearance.
- Optional 12-to-10-inch adapter configuration.
- Selectable cup-holder and grille option.
FOX BOX Ram Quad & Crew Cab Dual 12-Inch Vented Subwoofer Enclosure - 12"- NO ADAPTER NEEDED / No- I don't want cup holders and grills. is backordered and will ship as soon as it is back in stock.
FOX BOX Ram Quad & Crew Cab Dual 12-Inch Vented Subwoofer Enclosure - 12"- NO ADAPTER NEEDED / No- I don't want cup holders and grills. is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
This Fox Box enclosure is supplied empty and is shaped for the vehicle application listed in the specifications. Its physical layout is the mounting layout listed below.
This is an empty enclosure. Subwoofers, amplifiers and wiring are not included.
Key Features & Benefits
- Dual 12-inch vented layout tuned to 35 Hz.
- Two-piece enclosure design.
- Included 1.25-inch seat-lift kit for the required installation clearance.
- Optional 12-to-10-inch adapter configuration.
- Selectable cup-holder and grille option.
Technical Specifications
| Model | DQC-212-V |
|---|---|
| Vehicle application | 2002–2018 third- and fourth-generation Ram 1500/2500/3500 Quad and Crew Cab; 2019 and newer fifth-generation 2500/3500 Quad and Crew Cab; 2019 and newer Classic-body 1500/2500/3500 Quad and Crew Cab |
| Excluded application | Fifth-generation Ram 1500 |
| Enclosure type | Vented; two-piece design |
| Subwoofer configuration | Two 12-inch subwoofers; optional 10-inch adapter rings |
| Mounting cutout | 11.15 inches |
| Mounting depth | 7 inches |
| Maximum magnet diameter | 7.5 inches |
| Internal air volume | 1.55 cu ft per subwoofer |
| Tuning frequency | 35 Hz |
| Required seat lift | 1.25 inches; kit included |
| Physical options | 12-to-10-inch adapters; cup holders and grilles |
Why Choose This Product?
This empty enclosure has the vehicle-specific shape and mounting layout listed above. Physical fit limits include mounting depth: 7 inches. Review the interior-clearance and installation restrictions before ordering.
Installation & Compatibility Notes
- Does not fit the fifth-generation Ram 1500. Check the body generation as well as the year and cab style; a 2019 or newer Classic is a different application from the fifth-generation 1500.
- The included 1.25-inch seat-lift kit is required for proper fit.
- Subwoofers with larger frames may require the installer to trim the mounting opening. Compare the cutout, depth and magnet dimensions before selecting a subwoofer.
- Do not route the amplifier power cable beneath the enclosure. The close fit can cause a large cable to raise the box into the seat.
- Cup holders and grilles are included only when the corresponding physical option is selected.
Frequently Asked Questions
Will it fit a fifth-generation Ram 1500?
No. Fifth-generation fitment is limited to the stated 2500/3500 applications; Classic-body 1500 fitment is a separate category.
Can I install 10-inch subs?
Yes, select the 12-to-10-inch adapter-ring option and verify the chosen drivers’ enclosure requirements.
Can I install it without lifting the seat?
No. The included 1.25-inch seat-lift kit is required.
Explore More
Compare more FOX BOX enclosures and accessories at 12 Volt Outlet.
Gallery note: Installation examples show vehicles and other equipment that are not included. Only the empty enclosure or accessory described in this listing is included.
