FOX BOX Ram Quad & Crew Cab Single 10-Inch Vented Driver-Side Sub Box
Key features
- Driver-side single 10-inch layout.
- 1.0-cubic-foot vented enclosure tuned to 36 Hz.
- Required 1-inch seat-lift kit included.
- Optional 10-to-8-inch adapter ring.
FOX BOX Ram Quad & Crew Cab Single 10-Inch Vented Driver-Side Sub Box - NO ADAPTER RING is backordered and will ship as soon as it is back in stock.
FOX BOX Ram Quad & Crew Cab Single 10-Inch Vented Driver-Side Sub Box - NO ADAPTER RING is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
This Fox Box enclosure is supplied empty and is shaped for the vehicle application listed in the specifications. Its physical layout is the mounting layout listed below.
This is an empty enclosure. Subwoofers, amplifiers and wiring are not included.
Key Features & Benefits
- Driver-side single 10-inch layout.
- 1.0-cubic-foot vented enclosure tuned to 36 Hz.
- Required 1-inch seat-lift kit included.
- Optional 10-to-8-inch adapter ring.
Technical Specifications
| Model | DQC-110-V-D |
|---|---|
| Vehicle application | 2002–2018 third- and fourth-generation Ram 1500/2500/3500 Quad and Crew Cab; 2019 and newer fifth-generation 2500/3500 Quad and Crew Cab; 2019 and newer Classic-body 1500/2500/3500 Quad and Crew Cab |
| Excluded application | Fifth-generation Ram 1500 |
| Enclosure type | Vented; driver side |
| Subwoofer configuration | One 10-inch subwoofer; optional 8-inch adapter ring |
| Mounting cutout | 9.125 inches |
| Mounting depth | 7 inches |
| Maximum magnet diameter | 7.5 inches |
| Internal air volume | 1.0 cu ft |
| Tuning frequency | 36 Hz |
| Required seat lift | 1 inch; kit included |
| Bar-grille compatibility | Not compatible |
Why Choose This Product?
This empty enclosure has the vehicle-specific shape and mounting layout listed above. Physical fit limits include mounting depth: 7 inches. Review the interior-clearance and installation restrictions before ordering.
Installation & Compatibility Notes
- Does not fit the fifth-generation Ram 1500. Check the body generation as well as the year and cab style; a 2019 or newer Classic is a different application from the fifth-generation 1500.
- The included 1-inch seat-lift kit is required.
- Bar grilles are not compatible with this box.
- High-excursion subwoofers are not recommended because of the limited airspace and port size.
- Subwoofers with larger frames may require the installer to trim the mounting opening. Compare the cutout, depth and magnet dimensions before selecting a subwoofer.
Frequently Asked Questions
Can I use a high-excursion 10-inch sub?
It is not recommended. The enclosure’s published airspace and port dimensions are fixed compatibility limits.
Will a bar grille fit?
No. The source specifically excludes bar-grille compatibility.
Can I use an 8-inch driver?
An optional 10-to-8-inch adapter ring is offered; the driver must still suit the enclosure specifications.
