FOX BOX Ram Quad & Crew Cab Single 12-Inch Vented Passenger-Side Sub Box
Key features
- Passenger-side layout for one 12-inch subwoofer.
- 1.85-cubic-foot vented enclosure tuned to 34 Hz.
- Included 1.25-inch steel seat-lift kit.
- Optional 12-to-10-inch adapter ring.
- Selectable cup-holder and bar-grille options.
FOX BOX Ram Quad & Crew Cab Single 12-Inch Vented Passenger-Side Sub Box - YES- I want cup holders. / NO ADAPTER NEEDED-I'm using a 12 / YES- I want bar grills is backordered and will ship as soon as it is back in stock.
FOX BOX Ram Quad & Crew Cab Single 12-Inch Vented Passenger-Side Sub Box - YES- I want cup holders. / NO ADAPTER NEEDED-I'm using a 12 / YES- I want bar grills is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
This Fox Box enclosure is supplied empty and is shaped for the vehicle application listed in the specifications. Its physical layout is the mounting layout listed below.
This is an empty enclosure. Subwoofers, amplifiers and wiring are not included.
Key Features & Benefits
- Passenger-side layout for one 12-inch subwoofer.
- 1.85-cubic-foot vented enclosure tuned to 34 Hz.
- Included 1.25-inch steel seat-lift kit.
- Optional 12-to-10-inch adapter ring.
- Selectable cup-holder and bar-grille options.
Technical Specifications
| Model | DQC-112-V-P |
|---|---|
| Vehicle application | 2002–2018 third- and fourth-generation Ram 1500/2500/3500 Quad and Crew Cab; 2019 and newer fifth-generation 2500/3500 Quad and Crew Cab; 2019 and newer Classic-body 1500/2500/3500 Quad and Crew Cab |
| Excluded application | Fifth-generation Ram 1500 |
| Enclosure type | Vented; passenger side |
| Subwoofer configuration | One 12-inch subwoofer; optional 10-inch adapter ring |
| Mounting cutout | 11.15 inches |
| Mounting depth | 7 inches |
| Maximum magnet diameter | 7.5 inches |
| Internal air volume | 1.85 cu ft |
| Tuning frequency | 34 Hz |
| Required seat lift | 1.25 inches; steel kit included |
| Physical options | 12-to-10-inch adapter; cup holders; bar grilles |
Why Choose This Product?
This empty enclosure has the vehicle-specific shape and mounting layout listed above. Physical fit limits include mounting depth: 7 inches. Review the interior-clearance and installation restrictions before ordering.
Installation & Compatibility Notes
- Does not fit the fifth-generation Ram 1500. Check the body generation as well as the year and cab style; a 2019 or newer Classic is a different application from the fifth-generation 1500.
- Install the included 1.25-inch steel seat-lift kit; it is required for proper fit.
- Subwoofers with larger frames may require the installer to trim the mounting opening. Compare the cutout, depth and magnet dimensions before selecting a subwoofer.
- Cup holders, the adapter ring and bar grilles depend on the options selected.
Frequently Asked Questions
Which side of the truck is this box for?
It is the passenger-side enclosure.
Can it use a 10-inch subwoofer?
Yes, an optional 12-to-10-inch adapter ring is offered. Match the subwoofer to the listed volume and mounting dimensions.
Is the lift kit optional?
No. The included 1.25-inch steel seat-lift kit is required.
Explore More
Compare more FOX BOX enclosures and accessories at 12 Volt Outlet.
Gallery note: Installation examples show vehicles and other equipment that are not included. Only the empty enclosure or accessory described in this listing is included.
