Full Throttle Series High-Performance AGM Battery FT310-20L
Key features
- Chemistry: AGM lead-acid
- Nominal voltage: 12 V
- Capacity (20-hour rate): 20 Ah
- Cold-cranking current: 310 A (CCA)
- Dimensions (L × W × H, including terminals): 6.89 × 3.42 × 6.12 inches
- Terminals: M5TAS
Full Throttle Series High-Performance AGM Battery FT310-20L is backordered and will ship as soon as it is back in stock.
Full Throttle Series High-Performance AGM Battery FT310-20L is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The Full Throttle FT310-20L is a 12V high-performance AGM battery with 310 cold-cranking amps and 20 Ah capacity at the 20-hour rate. Its sealed, non-spillable construction and compact 20L group size make it a clearly specified option when choosing a replacement battery.
Key Features & Benefits
- High-compression cells: This cell construction is part of the battery’s high-performance design.
- Thin-plate pure-lead technology: A defining feature of the FT310-20L’s internal construction.
- Sealed, non-spillable design: The battery’s construction is specified as sealed and non-spillable.
- Durable ABS case: The outer case is made from ABS plastic.
Technical Specifications
| Specification | Value |
|---|---|
| Nominal voltage | 12V |
| Capacity | 20 Ah at the 20-hour rate; 19 Ah at the 10-hour rate |
| Cold-cranking amps (CCA) | 310A |
| Cranking amps / marine cranking amps (CA / MCA) | 385A |
| Pulse hot-cranking amps (PHCA) | 675A |
| Reserve capacity at 25A | 30 minutes |
| Internal resistance | 5.9 mΩ |
| Group size | 20L |
| Terminal type | M5TAS |
| Dimensions (L × W × H, including terminals) | 6.89 × 3.42 × 6.12 inches (175 × 87 × 156 mm) |
| Weight | 15.0 lb (6.8 kg) |
| Case | ABS plastic |
Why Choose This Product?
The FT310-20L provides several distinct cranking ratings, capacity figures, and reserve capacity measurements to help you compare battery requirements using the correct rating. Its 20L group size and stated dimensions also give you concrete measurements to check against your battery space.
Installation & Compatibility Notes
Before installation, compare the battery’s dimensions, including terminals, and M5TAS terminal type with your vehicle’s battery layout. Check that the vehicle’s battery requirements are compatible with the 12V rating and the FT310-20L specifications.
Frequently Asked Questions
What does the 20 Ah capacity refer to?
The FT310-20L is rated at 20 Ah at the 20-hour rate and 19 Ah at the 10-hour rate.
Which cold-cranking and cranking ratings does it have?
It is rated at 310A CCA, 385A CA / MCA, and 675A PHCA. These are separate ratings and should not be treated as interchangeable.
What are the battery dimensions?
Including terminals, it measures 6.89 × 3.42 × 6.12 inches (175 × 87 × 156 mm).
What should I check before buying?
Confirm your vehicle’s battery requirements, available space, and terminal layout against the FT310-20L’s specifications.
