Heise 9004 Pro Series LED Kit - Dual Beam
Key features
- Bulb format: 9004
- Power consumption: 70 W per set
- Core: 2 mm solid copper
- Housing construction: All metal
- Beam adjustment: Rotatable collar
- Intended use: Off-road only
Heise 9004 Pro Series LED Kit - Dual Beam is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The Heise 9004 Pro Series LED Kit (HE-9004PRO) gives compatible off-road vehicles a 16,000-lumen dual-beam headlight upgrade. Its 9004 / HB1 bulb design handles both high and low beams, while the rotatable collar lets you adjust beam orientation.
Key Features & Benefits
- 16,000-lumen output: The set is rated 260% brighter than stock halogen 9004 bulbs.
- Dual-beam design: One bulb provides both high- and low-beam functions in a 9004 / HB1 socket.
- Active cooling: An IC thermal controller, high-speed smart fan, and 2 mm solid copper core manage heat during use.
- Adjustable beam orientation: Rotate the collar to align the beam cutoff in projector or reflector housings.
- EMI filter: Built-in suppression helps limit radio interference for equipment such as CB, ham radio, and GPS systems.
Technical Specifications
| Specification | Detail |
|---|---|
| Brand | Heise LED |
| Manufacturer | Heise Universe Lighting Systems |
| Part Number | HE-9004PRO |
| Bulb Type | 9004 / HB1 |
| Beam Type | Dual Beam (Hi/Lo) |
| Brightness | 16,000 lm per set |
| Power Consumption | 70W per set |
| Operating Temperature | 46.1°C |
| Core Material | 2 mm solid copper thermodynamic core |
| Housing Material | All-metal construction |
| Beam Adjustment | Rotatable collar |
| Connection Type | Side-cable connection |
| Cooling System | IC thermal controller + high-speed smart fan |
| Polarity Protection | Built-in reverse polarity protection |
| EMI Suppression | Built-in EMI filter |
| Startup | Instantaneous full lumen |
| Intended Use | Off-road use only |
| Product Weight | 0.45 kg |
| Warranty | 3 years |
Why Choose This Product?
This kit combines a dual-beam 9004 / HB1 fit with a slim side-cable connection for a tidy installation in tight engine bays. Its all-metal housing, copper core, and active cooling components are designed to manage heat while the LEDs operate.
Beam alignment matters after an LED bulb change. The adjustable collar gives you a way to orient the beam for the headlight housing, while the built-in EMI filter is useful when your off-road setup includes radio or GPS equipment.
Installation & Compatibility Notes
Check that your vehicle uses a 9004 / HB1 dual-beam socket before choosing this kit. Installation is plug-and-play in most applications, with no relay harness required in most cases. The side-cable connection is intended to help keep the installation tidy in confined engine bays.
A CANBUS decoder is recommended for vehicles with CANBUS monitoring or LED warning lights. A relay harness is recommended for older wiring or high-draw applications. After installation, adjust the rotatable collar and check the beam cutoff against a wall before driving. This kit is labeled for off-road use only; the source identifies it as not DOT-certified for on-road use in the United States.
Frequently Asked Questions
Does this kit provide both high and low beams?
Yes. The 9004 / HB1 bulb is a dual-beam design for high- and low-beam functions.
How much power does the kit draw?
The listed draw is 70W per set. The product details also state 35W per bulb, or roughly 5.8A per bulb at 12V.
Will it work in projector or reflector headlights?
The rotatable collar allows beam orientation adjustments in either housing type. Check the cutoff after installation.
Do I need a CANBUS decoder or relay harness?
A decoder is recommended for vehicles with CANBUS monitoring or LED warning lights. A relay harness is recommended for older wiring or high-draw applications.
