Deaf Bonce MACHETE MFA-1.500 | 500 Watt Power Amplifier
Key features
- Amplifier channels: 1
- RMS output at 4 ohms: 210.0 W
- RMS output at 2 ohms: 360 W
- RMS output at 1 ohm: 500 W
Deaf Bonce MACHETE MFA-1.500 | 500 Watt Power Amplifier is backordered and will ship as soon as it is back in stock.
Deaf Bonce MACHETE MFA-1.500 | 500 Watt Power Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Get dedicated subwoofer power in a compact package with the Deaf Bonce MACHETE MFA-1.500 Class D car amplifier. Its single channel supports loads down to 1 ohm, with adjustable low-pass and subsonic filters for shaping the bass signal.
Key Features & Benefits
- Single-channel design: Gives your subwoofer its own amplifier channel.
- Three RMS power ratings: Choose a subwoofer load that matches the amplifier’s listed output.
- Adjustable low-pass filter: Set the upper bass frequency from 50 to 250 Hz.
- Adjustable subsonic filter: Set a filter from 10 to 55 Hz to manage very low frequencies.
- Compact enclosure: The 6.3 x 6 x 2.1 inch dimensions can help with planning a space-conscious installation.
Technical Specifications
| Model | MFA-1.500 |
| Class | D |
| Number of the channels | 1 |
| Frequency response | 10 - 250 Hz |
| 1 Ohm RMS Power (14.4 V) | 500 W |
| 2 Ohm RMS Power (14.4 V) | 360 W |
| 4 Ohm RMS Power (14.4 V) | 210 W |
| Minimum permissible load on the channel | 1 Ohm |
| Low pass filter | 50-250 Hz |
| Crossover | 24 dB/Oct |
| Subsonic filter | 10 - 55 Hz |
| Input terminal | 4 Ga |
| Output terminal | 8 Ga |
| Working voltage | 9 - 15 V |
| Signal-to-noise ratio | ��� 160 dB |
| Size (WxLxH) | 6.3 x 6 x 2.1 inch |
Why Choose This Product?
The MFA-1.500 offers different listed RMS outputs at 1, 2, and 4 ohms, so you can compare its ratings with your subwoofer’s load. Its bass-focused frequency response and adjustable filters provide control over the signal sent to the subwoofer.
The compact dimensions are useful when you are planning around limited vehicle space. The Class D design and single-channel format make this a dedicated amplifier option for a subwoofer-focused car audio system.
Installation & Compatibility Notes
Check your subwoofer’s impedance and power requirements against the amplifier’s ratings before choosing a setup. The minimum permissible channel load is 1 ohm; do not plan a load below that rating.
Allow for the 6.3 x 6 x 2.1 inch amplifier dimensions when planning placement. Its working voltage is 9 - 15 V. Confirm that your vehicle’s electrical system and installation meet the listed requirements.
Frequently Asked Questions
How much RMS power does the MFA-1.500 produce?
Its listed ratings are 500 W at 1 ohm, 360 W at 2 ohms, and 210 W at 4 ohms, each at 14.4 V.
What is the minimum permissible speaker load?
The minimum permissible load on the channel is 1 ohm. Match the connected subwoofer load to this limit and the amplifier’s power ratings.
Can I adjust which frequencies reach the subwoofer?
The amplifier has a 50-250 Hz low-pass filter and a 10 - 55 Hz subsonic filter. Its listed crossover is 24 dB/Oct.
How much space should I allow for the amplifier?
Its listed size is 6.3 x 6 x 2.1 inch (WxLxH). Check your intended mounting space against these dimensions.
What working voltage does it require?
The listed working voltage is 9 - 15 V. Check your vehicle’s electrical system against this range before installation.
