Deaf Bonce MACHETE MFA-2.320 | 320 Watt 2-channel amplifier
Key features
- Amplifier channels: 2
- RMS per channel at 4 ohms: 320 W
- RMS per channel at 2 ohms: 480 W
- Amplifier class: Class D
- Frequency response: 20 Hz - 20 kHz
- Crossover slope: 12 dB/octave
Deaf Bonce MACHETE MFA-2.320 | 320 Watt 2-channel amplifier is backordered and will ship as soon as it is back in stock.
Deaf Bonce MACHETE MFA-2.320 | 320 Watt 2-channel amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Build a two-channel car audio system around the Deaf Bonce MACHETE MFA-2.320 amplifier, with power for stereo speakers or a bridged subwoofer setup. Its adjustable high-pass and low-pass filters let you shape the signal for your system.
Key Features & Benefits
- Two-channel design: Use it for a stereo front stage or a bridged mono connection.
- Adjustable filters: Set the high-pass and low-pass filters from 50–12000 Hz to tailor frequency coverage.
- Simultaneous filter operation: Run both filters together when your setup needs more control over frequency separation.
- Flexible input sensitivity: The 0.4–8 V input range accommodates different head-unit and preamp signal levels.
- Compact dimensions: The 8.5 × 6 × 2.2-inch footprint helps with planning installations where space is limited.
Technical Specifications
| Model | MFA-2.320 |
| Class | D |
| Number of the channels | 2 |
| Frequency response | 20-20000 Hz |
| 2 Ohm RMS Power (14.4 V) | 480 W x 2 |
| 4 Ohm RMS Power (14.4 V) | 320 W x 2 |
| 4 Ohm RMS Power (Bridge) | 960 W x 1 |
| Minimum permissible load on the channel | 2 Ohm |
| Minimum permissible load in a bridge connection | 4 Ohm |
| Input SPL | 0.4 - 8V |
| Low pass filter | 50-12000 Hz |
| High pass filter | 50-12000 Hz |
| LPF and HPF simultaneous operation | True |
| Crossover | 12 dB/Oct |
| Input terminal | 4 Ga |
| Output terminal | 10 Ga |
| Working voltage | 9 - 15V |
| Signal-to-noise ratio | 90 dB |
| Size (WxLxH) | 8.5 x 6 x 2.2 inch |
Why Choose This Product?
The MFA-2.320 gives you a choice between two-channel operation and a bridged configuration, with different power ratings for each load. Its selectable filter ranges and 12 dB/Oct crossover provide practical adjustment options for integrating speakers or a subwoofer.
Installation & Compatibility Notes
Match the speaker load to the amplifier’s limits: each channel supports a minimum 2 Ohm load, while bridged operation requires at least 4 Ohm. Check your speakers’ impedance and the vehicle’s electrical system against the amplifier’s 9–15 V working range before installation.
Frequently Asked Questions
How much power does the MFA-2.320 deliver?
At 14.4 V, it is rated at 480 W x 2 into 2 Ohm or 320 W x 2 into 4 Ohm. Bridged output is rated at 960 W x 1 into 4 Ohm.
Can I use this amplifier with a subwoofer?
Its 4 Ohm bridged rating supports a bridged subwoofer setup. Confirm the subwoofer’s impedance meets the amplifier’s 4 Ohm minimum for bridge operation.
Can the high-pass and low-pass filters run together?
Yes. Both filters can operate simultaneously, and each has an adjustment range of 50–12000 Hz.
What should I check before installation?
Confirm the speaker or subwoofer load, available installation space, input signal level, and vehicle voltage range against the specifications above.
Explore More
Shop for the Deaf Bonce MACHETE MFA-2.320 at 12 Volt Outlet. Want to learn more about Deaf Bonce? Explore our Deaf Bonce brand profile.
| Model | MFA-2.320 |
| Class | D |
| Number of the channels | 2 |
| Frequency response | 20-20000 Hz |
| 2 Ohm RMS Power (14.4 V) | 480 W x 2 |
| 4 Ohm RMS Power (14.4 V) | 320 W x 2 |
| 4 Ohm RMS Power (Bridge) | 960 W x 1 |
| Minimum permissible load on the channel | 2 Ohm |
| Minimum permissible load in a bridge connection | 4 Ohm |
| Input SPL | 0.4 - 8V |
| Low pass filter | 50-12000 Hz |
| High pass filter | 50-12000 Hz |
| LPF and HPF simultaneous operation | True |
| Crossover | 12 dB/Oct |
| Input terminal | 4 Ga |
| Output terminal | 10 Ga |
| Working voltage | 9 - 15V |
| Signal-to-noise ratio | ��� 90 dB |
| Size (WxLxH) | 8.5 x 6 x 2.2 inch |
