Deaf Bonce MACHETE MLA-80.4 XS | 80 Watt 4-channel amplifier
Key features
- Amplifier channels: 4
- RMS per channel at 4 ohms: 80 W
- RMS per channel at 2 ohms: 125 W
- Amplifier class: Class D
- Frequency response: 20 Hz - 20 kHz
- Crossover slope: 12 dB/octave
Deaf Bonce MACHETE MLA-80.4 XS | 80 Watt 4-channel amplifier is backordered and will ship as soon as it is back in stock.
Deaf Bonce MACHETE MLA-80.4 XS | 80 Watt 4-channel amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Give your car audio system four amplified channels with the Deaf Bonce MACHETE MLA-80.4 XS, a Class D car amplifier. It delivers 80 W x 4 RMS at 4 ohms and supports low-pass and high-pass filtering.
Key Features & Benefits
- Four channels: Amplify four channels from one amplifier.
- Selectable power ratings: Choose between the listed 2-ohm and 4-ohm RMS ratings to match your system design.
- Bridge capability: The amplifier supports a 4-ohm bridged connection with a listed rating of 250 W x 1 RMS.
- Adjustable filters: Low-pass and high-pass filters each cover 40–400 Hz, with simultaneous operation supported.
- Class D design: The amplifier’s Class D classification identifies its amplifier type.
Technical Specifications
| Model | MLA-80.4 XS |
| Class | D |
| Number of the channels | 4 |
| Frequency response | 20-20000 Hz |
| 2 Ohm RMS Power (14.4 V) | 125 W x 4 |
| 4 Ohm RMS Power (14.4 V) | 80 W x 4 |
| 4 Ohm RMS Power (Bridge) | 250 W x 1 |
| Minimum permissible load on the channel | 2 Ohm |
| Minimum permissible load in a bridge connection | 4 Ohm |
| Low pass filter | 40-400 Hz |
| High pass filter | 40-400 Hz |
| LPF and HPF simultaneous operation | True |
| Crossover | 12 dB/Oct |
| Input terminal | 4 Ga |
| Output terminal | 8 Ga |
| Working voltage | 9 - 15V |
| Signal-to-noise ratio | ��� 85 dB |
| Size (WxLxH) | 6 x 43.2 x 1.4 inch |
Why Choose This Product?
The MLA-80.4 XS gives you four channels and the option to use a bridged connection, with minimum load ratings stated for both arrangements. Its adjustable filters and simultaneous low-pass and high-pass operation offer control over crossover setup.
Installation & Compatibility Notes
Before installation, match the speaker loads to the amplifier’s minimum permissible loads for channel or bridged operation. Confirm the vehicle’s electrical supply is within the listed working-voltage range, and plan wiring around the specified terminal sizes.
Frequently Asked Questions
How much RMS power does the MLA-80.4 XS provide?
At 14.4 V, it is rated at 125 W x 4 at 2 ohms or 80 W x 4 at 4 ohms. The listed 4-ohm bridged rating is 250 W x 1.
What is the minimum speaker load?
The minimum permissible load is 2 ohms per channel. For a bridged connection, the minimum is 4 ohms.
Can the low-pass and high-pass filters operate together?
Yes. The specifications list simultaneous LPF and HPF operation as True; both filters cover 40–400 Hz.
What are the amplifier’s dimensions?
The listed size is 6 x 43.2 x 1.4 inch (WxLxH). Check available mounting space against these dimensions before installation.
