Massive Audio H104X - 10" 2000 Watts RMS Dual 4 Ohm 3" V.C. Mega Subwoofer
Key features
- Subwoofer size: 10.0 inches
- RMS power per subwoofer: 2000 W
- Voice-coil options: D4
- Voice-coil diameter: 3 inches
- Cone: Non-Pressed Paper
- Basket: Cast Aluminum
Massive Audio H104X - 10" 2000 Watts RMS Dual 4 Ohm 3" V.C. Mega Subwoofer is backordered and will ship as soon as it is back in stock.
Massive Audio H104X - 10" 2000 Watts RMS Dual 4 Ohm 3" V.C. Mega Subwoofer is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The Massive Audio H104X 10-inch subwoofer gives high-power car audio systems a 2000 W RMS bass driver with a 3-inch dual 4 Ω voice coil. Its cast aluminum basket, 274 oz strontium magnet, and 20.5 mm X-Max support a design focused on controlled, high-excursion bass.
Key Features & Benefits
- Power handling: The 2000 W RMS rating and 4000 W peak rating distinguish continuous power handling from short-term peaks.
- Dual voice coil: The 3-inch dual 4 Ω coil gives you an option to consider when matching the subwoofer to an amplifier.
- Non-Pressed Paper cone: The lightweight cone is specified for accurate bass reproduction at high excursion.
- Cast aluminum basket: The rigid frame is designed to reduce flex and resonance during playback.
- High-excursion design: Tall and narrow foam surrounds and 20.5 mm X-Max support substantial cone travel.
- Heavy-duty connections: Direct input wire terminals and triple tinsel leads are built for demanding bass movement and current delivery.
Technical Specifications
| Specification | Value |
|---|---|
| Size | 10 inches |
| Peak Watts | 4000 W |
| RMS Watts | 2000 W |
| Cone | Non-Pressed Paper |
| Voice Coil | 3" Dual 4 Ohm |
| Surround | Tall and Narrow Foam |
| Magnet | 274 oz Strontium |
| Terminals | Heavy Duty Direct Input Wires Connection |
| Basket | Cast Aluminum |
| Tinsel Leads | Heavy Duty Triple |
| X-Max | 20.5 mm |
| SPL | 89 dB |
| Ported Box | See User Guide PDF |
| Sealed Box | See User Guide PDF |
| Fs | 38 Hz |
| Re | See User Guide PDF |
| Le | See User Guide PDF |
| BL | See User Guide PDF |
| Qms | 2.481 |
| Qes | See User Guide PDF |
| Qts | See User Guide PDF |
| Vas | 23.875 L |
| Cms | 59.6 um/N |
| Mms | 236.1 g |
| Sd | 0.053 sq cm |
| Vd | 1.08 L |
Why Choose This Product?
The H104X combines a 2000 W RMS rating with a 274 oz magnet, cast aluminum basket, and heavy-duty triple tinsel leads. These construction details make it a specific option for high-power car audio builds where bass control and substantial cone travel matter.
Its 89 dB SPL rating and 20.5 mm X-Max help you compare output and excursion when selecting a subwoofer for your system.
Installation & Compatibility Notes
Plan the enclosure and amplifier around the H104X’s 10-inch size, dual 4 Ω voice coils, and power ratings. The product details list both ported and sealed enclosure options; consult the User Guide PDF for enclosure guidance. Confirm your intended amplifier load and installation space before purchase.
Frequently Asked Questions
What are the H104X’s power ratings?
It is rated at 2000 W RMS and 4000 W peak. RMS and peak are separate ratings, so use the RMS figure when comparing continuous power handling.
What is the voice coil configuration?
The H104X has a 3-inch dual 4 Ω voice coil. Check your amplifier’s specifications and intended load when planning the system.
Can this subwoofer be used in a sealed or ported box?
Both enclosure types are listed. Consult the User Guide PDF for the recommended enclosure volumes and port tuning.
What are the subwoofer’s excursion and sensitivity ratings?
The listed X-Max is 20.5 mm, and the SPL rating is 89 dB.
Explore More
Shop for the Massive Audio H104X at 12 Volt Outlet. Want to learn more about Massive Audio? Explore our Massive Audio brand profile.
| Size | 10" |
| Peak Watts | 4000 |
| RMS Watts | 2000 |
| Cone | Non-Pressed Paper |
| Voice Coil | 3" Dual 4 Ohm |
| Surround | Tall and Narrow Foam |
| Magnet | 274oz Strontium |
| Terminals | Heavy Duty Direct Input Wires Connection |
| Basket | Cast Aluminum |
| Tinsel Leads | Heavy Duty Triple |
| X-Max | 20.5mm |
| SPL | 89dB |
| Ported Box | See User Guide PDF |
| Sealed Box | See User Guide PDF |
| Fs | 38Hz |
| Re | See User Guide PDF |
| Le | See User Guide PDF |
| BL | See User Guide PDF |
| Qms | 2.481 |
| Qes | See User Guide PDF |
| Qts | See User Guide PDF |
| Vas | 23.875 L |
| Cms | 59.6 um/N |
| Mms | 236.1 g |
| Sd | 0.053 sq cm |
| Vd | 1.08 L |
