Massive Audio TX2 Trident 2-Channel Marine Amplifier
Key features
- Peak Output Power @ 14.4V: 480W x 1 Max
- 1 Ohm RMS: n/a
- 2 Ohm RMS: 240W x 2
- 4 Ohm RMS: 120W x 2
- 4 Ohm Bridged: 480W x 1
- Input Level: 0.2~9.0v
Massive Audio TX2 Trident 2-Channel Marine Amplifier is backordered and will ship as soon as it is back in stock.
Massive Audio TX2 Trident 2-Channel Marine Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Add two amplified channels to your marine audio system with the Massive Audio TX2 Trident 2-Channel Marine Amplifier. Its published ratings are 240W RMS per channel at 2 ohms and 120W RMS per channel at 4 ohms.
Key Features & Benefits
- Moisture-resistant circuit board: Conformal Dura-Coated 320°F epoxy PC boards help resist moisture, dust, and extreme heat.
- Full-range digital design: A four-layer PCB with SMD parts supports the amplifier’s compact 1.6-inch-high profile.
- Noise reduction circuitry: Built-in noise reduction helps manage unwanted system noise.
- Hi-input functions: Auto-sensing turn-on and a 12V remote output for external devices are available with Hi-Inputs.
- Optional Bluetooth streaming: Add the optional UBT1 dongle for Bluetooth audio; Bluetooth is not built in.
- Protection circuitry: Advanced five-way protection circuitry is built in.
Technical Specifications
| Specification | Value |
|---|---|
| Peak Output Power @ 14.4V | 480W x 1 Max |
| 1 Ohm RMS | n/a |
| 2 Ohm RMS | 240W x 2 |
| 4 Ohm RMS | 120W x 2 |
| 4 Ohm Bridged | 480W x 1 |
| Input Level | 0.2~9.0v |
| Freq. Response | 10Hz~25KHz |
| THD at 4 Ohm Load 30% Rated Power | <0.03% |
| S/N Ratio | >110dB |
| Bass Boost | N/A |
| Minimum Load | 2 Ohm Stereo |
| Gain Remote | n/a |
| Dimensions | 1.6"H x 4.25"W x 7.80"L |
Additional features: Full MOSFET with high-grade switching devices; RCLX ~ Railcap Booster (Optional).
Why Choose This Product?
The TX2 combines a compact footprint with two-channel output ratings for marine audio systems. Its coated circuit board and built-in protection circuitry are useful design considerations when choosing an amplifier for a marine installation.
Installation & Compatibility Notes
Install the amplifier in a protected location. Its stated minimum load is 2 ohms in stereo; match your speaker load and connection setup to the published ratings before installation. The unit measures 1.6"H x 4.25"W x 7.80"L, so allow for its dimensions when planning placement.
Frequently Asked Questions
How much power does the TX2 provide?
It is rated at 240W RMS per channel at 2 ohms and 120W RMS per channel at 4 ohms. The published 4-ohm bridged rating is 480W x 1.
What is the minimum stereo load?
The listed minimum load is 2 ohms stereo. Check your speaker load and intended connection before installation.
Does the TX2 have built-in Bluetooth?
No. Bluetooth audio streaming requires the optional UBT1 dongle.
Can it turn on from a high-level input?
With Hi-Inputs, the amplifier has an auto-sensing turn-on function and a 12V remote output for external devices.
How much installation space does it need?
The amplifier measures 1.6"H x 4.25"W x 7.80"L. Plan placement around those dimensions and install it in a protected location.
