Data Interface - Chrysler 2004-2020 — AXDI-CH13
Key features
- For select Chrysler 2004-2020
- Designed for non-amplified and amplified systems
- Pre-wired for the Axxess SWC interface (sold separately)
- Note: If your vehicle is equipped with steering wheel controls and you wish to retain them, the required steering wheel control interface must be purchased separately
- Retains R.A.P. (Retained Accessory Power); Retains factory chimes
- Provides accessory power (12-volt 10-amp)
Data Interface - Chrysler 2004-2020 — AXDI-CH13 is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Retain select factory functions when you install an aftermarket radio in a supported 2004–2020 Chrysler vehicle with the AXDI-CH13 data interface. Its plug-and-play connection provides accessory power and Retained Accessory Power, with navigation outputs for parking brake, reverse, and speed sense.
Key Features & Benefits
- Factory feature retention: Retains factory chimes and, in supported vehicles, may retain blind spot detection.
- Accessory power and R.A.P.: Provides 12-volt, 10-amp accessory power and Retained Accessory Power.
- Navigation outputs: Supplies parking brake, reverse, and speed-sense outputs for navigation connections.
- Speaker system support: Designed for non-amplified and amplified systems, with a high-level speaker input.
- Update and steering control options: Includes a Micro “B” USB port for updating vehicle applications and is pre-wired for a separately sold Axxess steering wheel control interface.
Technical Specifications
| Model | AXDI-CH13 |
|---|---|
| Vehicle application | Chrysler 2004–2020 |
| System compatibility | Designed for non-amplified and amplified systems |
| Accessory power | 12-volt, 10-amp |
| Retained power feature | Retained Accessory Power (R.A.P.) |
| NAV outputs | Parking brake, reverse, speed sense |
| Speaker input | High-level speaker input |
| Factory features | Retains factory chimes; may retain blind spot detection in supported vehicles |
| Steering wheel control preparation | Pre-wired for an Axxess steering wheel control (SWC) interface; sold separately |
| Update connection | Micro “B” USB port for updating to the latest vehicle applications |
| Warranty | 1-year limited warranty |
Why Choose This Product?
The AXDI-CH13 is designed to help keep selected factory functions available while changing to an aftermarket radio. Its stated support for both amplified and non-amplified systems gives you an interface option for either system type, while the NAV outputs serve installations that need parking brake, reverse, and speed-sense signals.
Installation & Compatibility Notes
This interface is listed for Chrysler vehicles from 2004 through 2020. Check that your specific vehicle and factory system are supported before installation, since retained features can depend on the vehicle.
If you want to retain steering wheel controls, purchase the required Axxess SWC interface separately. The AXDI-CH13 is pre-wired for that interface, but the SWC interface is not included.
Frequently Asked Questions
Does the AXDI-CH13 retain steering wheel controls?
It is pre-wired for an Axxess steering wheel control interface. That interface must be purchased separately if you want to retain steering wheel controls.
What navigation outputs does this data interface provide?
It provides parking brake, reverse, and speed-sense outputs.
Can it retain factory chimes and blind spot detection?
It retains factory chimes. Blind spot detection retention is possible in supported vehicles.
Does it work with amplified and non-amplified systems?
It is designed for both system types. Confirm support for your specific vehicle and factory system before installation.
What is included for software or vehicle application updates?
The interface has a Micro “B” USB port for updating to the latest vehicle applications.
