Orion HCCA124 – 12 Inch Dual 4 Ohm High-Performance Subwoofer | 2500W RMS Bass Power
Key features
- Subwoofer size: 12.0 inches
- RMS power per subwoofer: 2500 W
- Voice-coil options: D4
- Voice-coil diameter: 4 inches
- Surround: NBR foam
- Dust cap: Polypropylene
Orion HCCA124 – 12 Inch Dual 4 Ohm High-Performance Subwoofer | 2500W RMS Bass Power is backordered and will ship as soon as it is back in stock.
Orion HCCA124 – 12 Inch Dual 4 Ohm High-Performance Subwoofer | 2500W RMS Bass Power is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Bring powerful low-frequency output to your car audio system with the Orion HCCA124 12-inch dual 4-ohm subwoofer. Its 2500W RMS power handling, 4-inch voice coil, and 445 oz triple-stack ceramic magnet are built for high-output bass systems.
Key Features & Benefits
- 2500W RMS / 10000W peak: Handles substantial power for demanding bass playback.
- Dual 4-ohm voice coils: Offer wiring flexibility when matching the subwoofer to an amplifier.
- 4-inch high-temperature voice coil: Helps manage heat during extended high-power use.
- Moisture- and UV-resistant paper cone: Helps the cone withstand environmental exposure.
- NBR foam surround: Supports controlled excursion and tight bass response.
- Sealed or ported enclosure use: Lets you choose between enclosure styles according to your system design.
Technical Specifications
| Brand | Orion |
|---|---|
| Model | HCCA124 |
| Product type | 12-inch subwoofer |
| Voice coil configuration | Dual 4 ohm |
| Power handling | 2500W RMS / 10000W peak |
| Voice coil diameter | 4 inches |
| Mounting depth | 261 mm / 10.28 inches |
| Cutout diameter | 292 mm / 11.5 inches |
| Overall diameter | 324.5 mm / 12.78 inches |
| Frequency response | 24 Hz – 100 Hz |
| Sensitivity | 84.22 dB |
| Cone | Moisture- and UV-resistant paper |
| Surround | NBR foam |
| Dustcap | Polypropylene |
| Magnet | 445 oz triple-stack ceramic |
| Enclosure types | Sealed and ported |
Why Choose This Product?
The HCCA124 combines high power handling with construction details aimed at managing heat and controlling cone movement. Its dual 4-ohm voice coils give you flexibility when planning amplifier loads, while the sealed or ported enclosure options let you shape your system around your preferred bass response.
Installation & Compatibility Notes
Check your enclosure’s mounting depth, cutout diameter, and available space against the listed dimensions before installation. Match the subwoofer’s dual 4-ohm voice coils and power ratings to your amplifier and system design.
Frequently Asked Questions
What are the HCCA124’s RMS and peak power ratings?
It is rated for 2500W RMS and 10000W peak power handling.
What does dual 4 ohm mean for system planning?
The subwoofer has two 4-ohm voice coils, providing wiring options for amplifier load matching.
What enclosure types can I use?
The HCCA124 is optimized for sealed and ported enclosures.
What mounting dimensions should I check?
Allow for a mounting depth of 261 mm / 10.28 inches and a cutout diameter of 292 mm / 11.5 inches. Its overall diameter is 324.5 mm / 12.78 inches.
Explore More
Shop for the Orion HCCA124 at 12 Volt Outlet. Want to learn more about Orion? Explore our Orion brand profile.
Recommended Monoblock Amplifiers
Power-matched options for one subwoofer or one complete loaded enclosure. We aim to include same-brand choices when their ratings qualify.
Loading amplifier suggestions…
Suggestions use 75–125% of the subwoofer’s RMS rating at the wiring load shown. Check wiring, enclosure needs, electrical capacity and installation space. Set gain and filters correctly to avoid overpowering the subwoofer. Buying more than one subwoofer changes the match.
