PowerBass S-1004 10" Subwoofer
Key features
- Subwoofer size: 10.0 inches
- RMS power per subwoofer: 275 W
- Voice-coil options: S4
- Frequency response: 33 Hz - 500 Hz
- Voice-coil diameter: 2 in
- Cone material: Pressed Wool / Paper
PowerBass S-1004 10" Subwoofer is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Bring deep bass into a compact car audio build with the PowerBass S-1004 10-inch subwoofer. Its 4-ohm design, 275W RMS power handling and enclosure flexibility make it a practical choice for small sealed or ported systems.
The DDC-coated paper/wool cone, large foam surround and oversized motor structure are designed to support controlled movement during demanding bass passages. Use it in a compact two- or three-seat vehicle system where space is at a premium.
Key Features & Benefits
- DDC-coated paper/wool cone: A stiff cone helps keep movement controlled for low-distortion bass.
- Large roll foam surround: Supports linear cone movement and controlled excursion at higher output.
- Vented coil cooling: The 2-inch BASV voice coil former is vented to help dissipate heat during extended bass use.
- Stamped steel basket: The non-resonant, DDC-coated basket includes perimeter aero-vent cooling to help reduce mechanical noise and temperature rise.
- Compact enclosure options: Designed for small sealed or ported enclosures, giving you flexibility when planning a space-conscious build.
Technical Specifications
| Specification | Details |
|---|---|
| Model | PowerBass S-1004 |
| Driver size | 10 inches |
| Nominal impedance | 4 ohms |
| Power handling | 275W RMS / 550W peak (max) |
| Cone | Proprietary DDC-coated paper/wool |
| Surround | Large roll foam |
| Voice coil former | 2-inch BASV, vented coil cooling |
| Basket | Non-resonant DDC-coated stamped steel with perimeter aero-vent cooling |
| Enclosure compatibility | Small sealed or ported enclosures |
| Frequency response | 33 Hz–500 Hz |
| Sensitivity | 86 dB (1W/1M) |
| Cutout diameter | 9 1/8 inches (230.1 mm) |
| Mounting depth | 5.25 inches |
| Xmax | 9 mm |
| Motor structure | 116 oz |
| Sd | 330.06 cm² |
| Vas | 43.8 Ltr |
Why Choose This Product?
The S-1004 pairs a compact enclosure design with substantial power handling for a space-conscious bass system. Its 33 Hz lower frequency response and 9 mm Xmax support bass fundamentals, while the cooling features are designed for demanding listening sessions.
The 4-ohm impedance gives you an important matching point when selecting an amplifier. Check its output at that load and compare it with the subwoofer’s RMS rating to plan a suitable system.
Installation & Compatibility Notes
Allow for the 9 1/8-inch cutout diameter and 5.25-inch mounting depth when checking available space. The driver is designed for small sealed or ported enclosures; confirm your enclosure is appropriate for the S-1004 before installation.
Match the amplifier and subwoofer at the stated 4-ohm impedance, and use the RMS power rating when assessing amplifier output. The supplied details do not give an enclosure volume or tuning frequency, so do not assume a specific box design.
Frequently Asked Questions
What enclosure types suit the PowerBass S-1004?
It is designed for small sealed or ported enclosures. Choose an enclosure that fits your available space and is appropriate for this driver.
What amplifier power should I consider?
The subwoofer is rated at 275W RMS and 550W peak (max). Compare amplifier output at 4 ohms with the RMS rating when planning your system.
What is the S-1004’s impedance?
Its nominal impedance is 4 ohms, which is a key figure for matching it to an amplifier.
How much mounting space does it need?
Plan for a 9 1/8-inch (230.1 mm) cutout diameter and 5.25-inch mounting depth, then check the available space in your installation location.
What frequency range and sensitivity are listed?
The listed frequency response is 33 Hz–500 Hz, and sensitivity is 86 dB at 1W/1M.
