PowerBass XL-1044 10" Subwoofer
Key features
- Subwoofer size: 10.0 inches
- RMS power per subwoofer: 350 W
- Voice-coil options: S4
- Mounting depth: 5.25 in
- Voice-coil diameter: 2 in
- Cone material: Non Pressed Paper
PowerBass XL-1044 10" Subwoofer is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Add controlled low-end bass to a compact car audio build with the PowerBass XL-1044 10-inch subwoofer. Its 4-ohm impedance, 350W RMS power handling, and design for small sealed or ported enclosures make it a flexible option when installation space is limited.
Key Features & Benefits
- 350W RMS power handling: Provides headroom for demanding bass passages when paired with a suitable amplifier.
- DDC-coated paper cone: The non-pressed cone is designed to help control breakup and maintain linear response.
- Santoprene surround: The large-roll surround supports sustained cone movement at high output.
- Vented voice coil former: The 2.0-inch BASV former and perimeter aero-vent cooling vents aid thermal management during extended playback.
- Non-resonance basket: The polycarbonate and glass fiber construction is designed to reduce coloration while maintaining rigidity.
- Compact mounting dimensions: A 9 5/16-inch cutout diameter and 5.25-inch mounting depth help with planning tight installations.
Technical Specifications
| Specification | Value |
|---|---|
| Model | PowerBass XL-1044 |
| Product type | 10-inch subwoofer |
| Nominal impedance | 4 ohms |
| Power handling | 350W RMS / 700W peak |
| Frequency response | 28 Hz – 350 Hz |
| Sensitivity | 85.60 dB (1W/1M) |
| Cone | Proprietary non-pressed paper, DDC-coated |
| Surround | Large Roll Santoprene |
| Voice coil former | 2.0-inch vented BASV |
| Cooling | Perimeter aero-vent cooling vents |
| Basket | Proprietary non-resonance polycarbonate/glass fiber |
| Terminals | Chrome push terminals |
| Enclosure compatibility | Small sealed or ported enclosures |
| Cutout diameter | 9 5/16" (237 mm) |
| Mounting depth | 5.25" |
| Magnet size | 164 oz |
| Xmax | 8 mm |
| Fs | 29.8 Hz |
| Qts | 0.387 |
| Qes | 0.423 |
| Qms | 4.558 |
| Vas | 36.31 Ltr |
| Sd | 363.05 cm² |
| Voice coil size | 2" |
Why Choose This Product?
The XL-1044 combines a 164 oz magnet and a rigid, non-resonance basket with a coated cone and Santoprene surround. These design details support controlled bass in compact builds, while the stated 28 Hz lower frequency limit and 85.60 dB sensitivity help you assess its place in your system.
Its sealed-or-ported enclosure design gives you options when choosing how to use limited trunk or cabin space. The vented former and cooling vents also help manage heat during extended bass playback.
Installation & Compatibility Notes
Plan around the 9 5/16-inch (237 mm) cutout diameter and 5.25-inch mounting depth. Confirm your available mounting space and enclosure design before installation.
Match the subwoofer’s nominal 4-ohm impedance and 350W RMS power handling with your amplifier’s output ratings. The XL-1044 is designed for small sealed or ported enclosures.
Frequently Asked Questions
What do the 350W RMS and 700W peak ratings mean?
The subwoofer is rated for 350W RMS and 700W peak. Use the RMS rating when comparing continuous amplifier output at the subwoofer’s 4-ohm impedance.
What enclosure types can I use?
The XL-1044 is designed for small sealed or ported enclosures. Choose an enclosure that suits your available space and installation plan.
How much mounting space does it need?
Allow for a 9 5/16-inch (237 mm) cutout diameter and 5.25-inch mounting depth, along with the clearance required by your installation.
What should I check when selecting an amplifier?
Check that the amplifier supports a 4-ohm load and compare its output rating with the subwoofer’s 350W RMS power handling.
