Rockford Fosgate Punch P300X1 300 Watt Monoblock Amplifier
Key features
- Amplifier channels: 1
- RMS output at 4 ohms: 200.0 W
- RMS output at 2 ohms: 300 W
- Frequency response: 20 Hz–20 kHz
- Input sensitivity: 150 mV–12 V
- Crossover: variable 50–250 Hz high-pass/low-pass, 12 dB/octave
Rockford Fosgate Punch P300X1 300 Watt Monoblock Amplifier is backordered and will ship as soon as it is back in stock.
Rockford Fosgate Punch P300X1 300 Watt Monoblock Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The Rockford Fosgate Punch P300X1 is a 1-channel monoblock amplifier for a subwoofer or dedicated center channel. It delivers up to 300 watts at 2 ohms, with adjustable crossovers and onboard Punch EQ for tuning your system.
High-level inputs with Auto Turn-On support integration with a factory radio, while RCA pass-thru outputs let you link another amplifier.
Key Features & Benefits
- Power at 2 ohms: The 300-watt rating supports a compatible low-impedance load.
- Adjustable filtering: High-pass and low-pass Butterworth crossovers cover a 50–250 Hz range for system tuning.
- Onboard Punch EQ: Bass and treble adjustments let you shape the sound without an external processor.
- Factory-radio integration: High-level inputs and Auto Turn-On allow speaker-level connection and signal-triggered startup.
- Flexible expansion: RCA pass-thru outputs link additional amplification, and the amp is ready for an optional PLC2 remote.
- Protected, compact design: Short-circuit and over-current protection pair with a cast aluminum heatsink and top-mounted controls.
Technical Specifications
| Specification | Details |
|---|---|
| Channels | 1-channel monoblock |
| Power output | 200W x 1 @ 4 Ω; 300W x 1 @ 2 Ω |
| Dynamic power | 260W x 1 @ 4 Ω; 444W x 1 @ 2 Ω |
| Crossover | 12dB/oct Butterworth; High-Pass and Low-Pass, 50–250 Hz range; All-Pass available |
| Setup features | C.L.E.A.N. Set-up |
| Inputs | Hi/Lo level inputs via 1 RCA pair; high-level input with Auto Turn-On |
| Outputs | 1 RCA pass-thru output |
| Punch EQ | Bass boost +18dB @ 45Hz; Treble boost +12.5dB @ 12kHz |
| Remote | Optional PLC2 remote-ready |
| Protection | Short circuit and over-current protection |
| Construction and features | Cast aluminum heatsink; muted turn-on; stealth top-mounted control panel |
| Compliance | CTA-2006 compliant |
| Operating voltage | 9–16 V |
| Input sensitivity | 150 mV–12 V |
| Average efficiency | 74% at 4 Ω |
| THD | <1.0% @ 4 Ω; <1.0% @ 2 Ω |
| Dimensions | 2.38" H × 7.76" W × 9.86" D (in); 6.05 cm × 19.71 cm × 25.04 cm |
| Shipping weight | 9.5 lb (4.30 kg) |
Why Choose This Product?
The P300X1 combines single-channel subwoofer power with practical tuning controls in one amplifier. Its crossover options help shape the signal for your system, while Punch EQ offers bass and treble adjustments on the amp itself.
For a system that may expand later, the RCA pass-thru output provides a way to link another amplifier. The optional PLC2 remote-ready feature adds a remote-control option.
Installation & Compatibility Notes
Check your subwoofer’s impedance and power requirements against the amplifier’s ratings before connecting it. The stated operating voltage is 9–16 V.
Allow for the amplifier’s 2.38" H × 7.76" W × 9.86" D dimensions when planning its mounting location. High-level inputs support speaker-level connections; RCA inputs are also provided.
Frequently Asked Questions
How much power does the P300X1 deliver?
It is rated at 200W x 1 at 4 Ω and 300W x 1 at 2 Ω. Dynamic power is 260W x 1 at 4 Ω and 444W x 1 at 2 Ω.
Can I connect it to a factory radio?
Yes. Its high-level input supports speaker-level connections, and Auto Turn-On powers the amplifier when signal is present.
What crossover and tone controls are included?
It has 12dB/oct Butterworth high-pass and low-pass crossovers with a 50–250 Hz range, plus an All-Pass option. Punch EQ provides bass boost of +18dB at 45Hz and treble boost of +12.5dB at 12kHz.
Can I add a remote or link another amplifier?
The amp is ready for an optional PLC2 remote and has one RCA pass-thru output for linking additional amplification.
