Rockford Fosgate Power Series T2500-BDCP 2,500 Watt Monoblock Amplifier
Key features
- Amplifier channels: 1
- RMS output at 4 ohms: 1500.0 W
- RMS output at 2 ohms: 2500 W
- RMS output at 1 ohm: 2500 W
Rockford Fosgate Power Series T2500-BDCP 2,500 Watt Monoblock Amplifier is backordered and will ship as soon as it is back in stock.
Rockford Fosgate Power Series T2500-BDCP 2,500 Watt Monoblock Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Put serious power behind a bass system with the Rockford Fosgate Power Series T2500-BDCP monoblock amplifier. Its bdCP Constant Power design delivers up to 2,500 watts RMS at 1 ohm, while PowerSync/bdSYNC supports combining two amplifiers into a 5,000-watt system.
Use its adjustable filters to shape the low-frequency signal for your build. RCA pass-through and MasterSync also give you options when planning a larger amplifier array.
Key Features & Benefits
- Low-impedance power: Rated for 2,500 watts RMS at 1 ohm and 2 ohms, giving you flexible load options.
- Scalable system design: bdSYNC can strap two amplifiers together for a single 5,000-watt system.
- Adjustable bass filtering: The low-pass filter, infrasonic filter, and bass boost let you tailor the signal.
- Signal routing: One RCA input and one pass-through output support signal daisy-chaining.
- Installation connections: 1/0 AWG power and ground connectors accommodate the stated power wiring size.
- Status indicators: Power, Thermal, Protect, and blue signal/power LEDs help you monitor amplifier status.
Technical Specifications
| Specification | Details |
|---|---|
| Channels | 1-channel monoblock |
| RMS power by impedance | 1,500W @ 4Ω; 2,500W @ 2Ω and 1Ω |
| Dynamic power | 1: 4Ω 1,823W, 2Ω 2,940W, 1Ω 2,980W |
| PowerSync / bdSYNC | bdSYNC lets two amplifiers be strapped together for a single 5,000W system |
| MasterSync | Enables one amplifier to control an array of amplifiers |
| Crossover / filtering | 24dB/Octave Low-Pass 35–250 Hz; infrasonic 12dB/Octave (-3 dB at 28 Hz); bass boost up to +18 dB @ 45 Hz |
| Inputs / outputs | 1 RCA input; 1 RCA pass-through output for signal daisy-chaining |
| Phase | 0°/180° phase switch |
| Protection and indicators | Power, Thermal, and Protect LEDs; blue LED indicators for signal/power monitoring |
| Topology | Class BD; MOSFET power supply and MOSFET output stage |
| Rated efficiency | 64.5% at 1Ω; 77.7% at 2Ω; 81.9% at 4Ω |
| Input sensitivity | 150 mV to 4 V |
| Power / ground connectors | 1/0 AWG |
| Speaker wire connections | 8–16 AWG |
| Cooling | Convection heatsink |
| Dimensions | 2.14" H x 8.14" W x 21.875" D |
| Operating voltage | 9–16 VDC |
| Recommended fuse | 300 A |
| Average current draw | 175 A @ 13.8 V |
| Maximum current draw | 350 A |
| Remote | Optional remote PEQ |
| Compliance | CTA-2006 compliant |
| Warranty | 2-year warranty |
Why Choose This Product?
The T2500-BDCP is built for bass-focused systems that need substantial output at low impedance. Its ratings include both 1Ω and 2Ω operation, and bdSYNC offers a defined path to a two-amplifier, 5,000-watt setup.
For a larger array, MasterSync lets one amplifier control the array. The RCA pass-through provides another way to route the signal between components, while the phase switch supports phase alignment.
Installation & Compatibility Notes
Plan for the amplifier’s 2.14" H x 8.14" W x 21.875" D dimensions and its stated 1/0 AWG power and ground connections. Speaker wire connections are listed for 8–16 AWG.
Its operating range is 9–16 VDC, with a recommended 300 A fuse, average current draw of 175 A at 13.8 V, and maximum draw of 350 A. Check available space and the vehicle’s electrical system against these requirements before installation.
Frequently Asked Questions
How much RMS power does the T2500-BDCP produce at 1 ohm?
It is rated at 2,500 watts RMS at 1Ω. It is also rated at 2,500 watts RMS at 2Ω and 1,500 watts RMS at 4Ω.
Can I combine two T2500-BDCP amplifiers?
Yes. The bdSYNC feature lets two amplifiers be strapped together for a single 5,000W system.
What filtering adjustments does this amplifier offer?
It has a 35–250 Hz low-pass filter, an infrasonic filter, and bass boost up to +18 dB at 45 Hz.
What power wiring and fuse are specified?
The power and ground connectors are specified for 1/0 AWG, and the recommended fuse is 300 A.
Does it include a remote control?
An optional remote PEQ is listed for this amplifier.
