Rockford Fosgate Power Series T600-4 4-Channel Amplifier
Key features
- Amplifier channels: 4
- RMS per channel at 4 ohms: 100 W
- RMS per channel at 2 ohms: 150 W
- Frequency response: 20 Hz–20 kHz (±1 dB)
- Input sensitivity: 150 mV–5 V (RCA)
- Crossover: variable 50–500 Hz, 24 dB/octave Butterworth
Rockford Fosgate Power Series T600-4 4-Channel Amplifier is backordered and will ship as soon as it is back in stock.
Rockford Fosgate Power Series T600-4 4-Channel Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Build a four-channel car audio system around the Rockford Fosgate Power Series T600-4 amplifier, with 600 watts total RMS power and crossover controls for shaping your speaker output. Its flexible channel options support front and rear speakers or bridged operation for subwoofers.
Key Features & Benefits
- Flexible power options: Choose four-channel output or bridge channels for a different system layout.
- Adjustable crossovers: Set high-pass or low-pass filtering from 50–500 Hz on the front and rear channels.
- Signal input selection: Switch between 2- and 4-channel inputs to match your source signal setup.
- Tone controls: Adjust front and rear treble and bass EQ to shape the sound in your vehicle.
- RCA pass-through: Send the input signal to additional amplifiers without adding splitters.
- Protection indicators: Power and Thermal Protect indicators help you check amplifier status.
Technical Specifications
| Specification | Details |
|---|---|
| Amplifier type | 4-channel amplifier |
| Total RMS power | 600 Watts |
| RMS power at 4Ω | 100W x4 |
| RMS power at 2Ω | 150W x4 |
| Bridged RMS power at 4Ω | 300W x2 |
| Bridged operation | Supports two 2Ω bridged channels for subwoofers; bridgeable operation supports driving subs via 2Ω per bridged pair |
| Output stage | High-current MOSFET |
| Power and ground connectors | 4 Gauge |
| Input selection | 2/4 Channel Input Switch |
| Front and rear crossovers | High-pass and low-pass options, 50–500 Hz; 24dB/octave Butterworth slopes |
| Front and rear treble EQ | 0–12 dB at 12 kHz |
| Front and rear bass EQ | 0–18 dB at 45 Hz |
| Low-level inputs | Front: 1 RCA; Rear: 1 RCA |
| Low-level output | Single low-level output |
| Operating voltage | 9–16 VDC |
| Maximum current draw | 80 A |
| Recommended fuse | 80 A |
| Efficiency | 70%–64% depending on load |
| Cooling | Convection heat sink |
| Indicators | Power and Thermal Protect |
| Compliance | CTA-2006 Compliant |
| Warranty | 2-Year Warranty |
| Dimensions | 2.14" H × 8.14" W × 14.91" D (5.42 × 20.68 × 37.86 cm) |
| Weight | 12 lb (5.44 kg) |
Why Choose This Product?
The T600-4 gives you multiple ways to configure a four-channel system without limiting you to one speaker arrangement. Use its front and rear crossover controls to tailor signal routing, then adjust the separate EQ sections for treble and bass.
Its RCA pass-through output also provides a signal path to additional amplifiers. That can help when you expand a system and need to connect more amplification.
Installation & Compatibility Notes
Plan for the amplifier’s 2.14" H × 8.14" W × 14.91" D dimensions and 12 lb weight when checking a mounting location. Its power and ground connectors accept 4 Gauge wiring. The stated operating range is 9–16 VDC, with an 80 A maximum current draw and an 80 A recommended fuse.
Match speaker loads and bridged configurations to the ratings above, and confirm your source provides the appropriate 2- or 4-channel signal. The product description also refers to standard wiring harnesses.
Frequently Asked Questions
How much RMS power does the T600-4 deliver?
It is rated at 100W x4 at 4Ω, 150W x4 at 2Ω, or 300W x2 when bridged at 4Ω.
Can this amplifier power subwoofers?
It supports bridged operation for subwoofers. The supplied details list 300W x2 bridged at 4Ω and also state support for two 2Ω bridged channels.
What crossover adjustments are available?
Front and rear channels offer high-pass and low-pass options from 50–500 Hz, with 24dB/octave Butterworth slopes.
What electrical requirements should I plan around?
The amplifier operates at 9–16 VDC, draws up to 80 A, and has an 80 A recommended fuse.
