SoundQubed C4-2800 4-Channel Full-Range Amplifier
Key features
- Amplifier channels: 4
- RMS per channel at 4 ohms: 350 W
- RMS per channel at 2 ohms: 700 W
- Overall dimensions: 9.53 x 5.91 x 2.17 inches
- Amplifier design: Full-range 4-channel
- Power input terminals: 4 AWG
SoundQubed C4-2800 4-Channel Full-Range Amplifier is backordered and will ship as soon as it is back in stock.
SoundQubed C4-2800 4-Channel Full-Range Amplifier is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
Give your car or motorcycle speaker system four channels of full-range amplification in a compact chassis with the SoundQubed C4-2800 4-Channel Full-Range Amplifier. It delivers 350 watts RMS per channel at 4 ohms or 700 watts RMS per channel at 2 ohms, with crossover options for different system setups.
Key Features & Benefits
- Four-channel output: Power four channels from one compact amplifier chassis.
- High RMS ratings: Choose between 350 watts RMS per channel at 4 ohms and 700 watts RMS per channel at 2 ohms.
- Flexible channel controls: Channels 1/2 offer high-pass or full-range operation, while channels 3/4 add band-pass operation.
- Frequency multiplier: Adjust the crossover range on channels 3/4 using the frequency multiplier.
- Bridged operation: Configure two channels for 1,400 watts RMS at 4 ohms.
- Status indicators and protection: Power, protect and clip indicators provide a quick status check; built-in protection covers thermal overload, overload, DC output, short circuits, input voltage and clipping.
Technical Specifications
| Specification | Value |
|---|---|
| Channels | 4 |
| RMS power at 4 ohms | 350W x 4 |
| RMS power at 2 ohms | 700W x 4 |
| Bridged RMS power at 4 ohms | 1400W x 2 |
| Minimum impedance | 2 ohms stereo / 4 ohms bridged |
| Frequency response | 10Hz–25kHz |
| Signal-to-noise ratio | 95dB |
| Low-level input range | 400mV–6V |
| THD | 0.10% |
| Power input terminals | 4 AWG |
| Recommended fuse | 250A |
| Overall dimensions | 9.53 x 5.91 x 2.17 inches (L x W x H) |
Why Choose This Product?
The C4-2800 combines four-channel output with channel-specific crossover options, giving you flexibility when planning your speaker system. Its compact chassis is intended for installations where a full-size amplifier footprint is not wanted.
Installation & Compatibility Notes
Before ordering, check the available mounting space, speaker impedance and electrical supply. Allow clearance for wiring and ventilation. For motorcycle installations, choose a protected mounting location; placement in a motorcycle collection does not imply a waterproof rating.
Frequently Asked Questions
Can the C4-2800 power a car or motorcycle speaker system?
It is described for car or motorcycle speaker systems. Check your available mounting space, speaker impedance and electrical supply before ordering.
What crossover operation is available?
Channels 1/2 support high-pass or full-range operation. Channels 3/4 also support band-pass operation and have a frequency multiplier for the crossover range.
What should I plan for when mounting it?
Check the 9.53 x 5.91 x 2.17-inch overall dimensions and leave clearance for wiring and ventilation.
Is it waterproof for motorcycle use?
A motorcycle collection placement does not indicate a waterproof rating. Use a protected mounting location.
