VFL Audio VFL Series 6.5" Subwoofer Dual 4 Ohm
Key features
- Subwoofer size: 6.5 inches
- RMS power per subwoofer: 300 W
- Voice-coil options: D4
- Mounting depth: 4.06 inches
- Cutout size: 5.98 inches
- Voice-coil diameter: 2 inches
VFL Audio VFL Series 6.5" Subwoofer Dual 4 Ohm is backordered and will ship as soon as it is back in stock.
Description
Description
Product Overview
The VFL Audio VFL Series 6.5-inch subwoofer brings 300W RMS power to a compact subwoofer format. Its dual 4-ohm impedance, 2-inch voice coil, and 70-ounce magnet define its key design specifications.
Key Features & Benefits
- 300W RMS power: Gives you the continuous power rating to consider when matching an amplifier.
- Dual 4-ohm impedance: Helps you assess the subwoofer’s electrical load when planning your system.
- 2-inch voice coil: Provides a specific component detail for comparing subwoofers.
- Compact mounting dimensions: The 4.06-inch mounting depth and 5.98-inch cutout size help you check available space.
Technical Specifications
| RMS POWER | 300 |
| MAX POWER | 600 |
| IMPEDANCE (OHMS) | D4 |
| SENSITIVITY DB | 81.2 |
| MOUNTING DEPTH (IN) | 4.06 |
| CUTOUT SIZE (IN) | 5.98 |
| PORTED BOX (FT3) | 0.6 |
| MAGNET SIZE (OZ) | 70 |
| VOICE COIL SIZE | 2" |
| BASKET TYPE | CAST |
| RECOMMENDED AMP (PAIR) | VFL 1K |
Why Choose This Product?
This VFL Series subwoofer pairs a 6.5-inch size with a 300W RMS rating, giving you specific power and fitment figures to consider when planning a system. The cast basket, 70-ounce magnet, and 2-inch voice coil provide further details for comparing it with other subwoofers.
Installation & Compatibility Notes
Check that your mounting location accommodates the 4.06-inch mounting depth and 5.98-inch cutout. The listed ported box volume is 0.6 ft³.
Account for the dual 4-ohm impedance when planning amplifier and system connections. The recommended amplifier for a pair is the VFL 1K.
Frequently Asked Questions
What is the RMS power rating?
The VFL Series 6.5-inch subwoofer is rated at 300 RMS. Its listed maximum power is 600.
What does D4 impedance mean for system planning?
D4 identifies the subwoofer as dual 4-ohm. Consider that rating when planning your amplifier and connections.
What space does it need for mounting?
Allow for a 4.06-inch mounting depth and a 5.98-inch cutout.
What amplifier is recommended for a pair?
The listed recommendation is the VFL 1K.
